Harman Kardon CDR2 Technical Manual

- 8 -
4. POWER LEVER ASSEMBLY REMOVAL
1. Pull-out the Power Lever assembly( ) from Power Switch on the PCB-1.
2. Pull-out the Power Knob assembly( ) from the power Lever( )
3. Remove the PCB-8(Power LED ) from the Power Knob assembly( )
2
1
3
4
3. FRONT PANEL ASSEMBLY REMOVAL
5112 76 2
4
8
910
11
3
1. Detach the connector to in Fig.3
2. Remove the front panel by hook-off to in Fig.3 and
pulling it toward you gently.
3. Detach the connector
<Fig 3>
<Fig 4>
➊
➌➊
➍➌
➊
➊➐
12
11
