R649,651,668,679,684 0RH1000C622 100 1/16W 5 D.R/TP
R670,686,687,998 0RH0000C622 0 1/16W 5 D.R/TP
R677,694,864,971,972 0RH0000C622 0 1/16W 5 D.R/TP
R692,696,697 0RH1001C422 1K 1/16W 1% D R/TP
R701,702,703,704 0RH6801C622 6.8K 1/16W 5 D.R/TP
R705,706,707,708 0RH1802C622 18K 1/16W 5 D.R/TP
R710,906,925,975 0RH2201C622 2.2K 1/16W 5 D.R/TP
R713,714 0RH1802C622 18K 1/16W 5 D.R/TP
R715,716 0RH6802C622 68K 1/16W 5 D.R/TP
R719,725,901,902,918 0RH1002C622 10K 1/16W 5 D.R/TP
R723 0RH1502C622 15K 1/16W 5 D.R/TP
R726,727,851,917,922 0RH4701C622 4.7K 1/16W 5 D.R/TP
R730,751,752,753 0RH1000C622 100 1/16W 5 D.R/TP
R732 0RH8200C422 820 OHM 1/16W 1608 1% D R/TP
R754,961 0RH1003C622 100K 1/16W 5 D.R/TP
R755 0RH5602C622 56K 1/16W 5 D.R/TP
R756 0RH3302C622 33K 1/16W 5 D.R/TP
R760 0RH7502C622 75K 1/16W 5 D.R/TP
R761 0RH2703C622 270K 1/16W 5 D.R/TP
R854,855,856,857 0RH2701C422 2.70K 1/16W 1% D R/TP
R862,916,923 0RH1004C622 1M 1/16W 5 D.R/TP
R907,908,927,928 0RH1203C622 120K 1/16W 5 D.R/TP
R910,930 0RH8201C622 8.2K 1/16W 5 D.R/TP
R911,915,924,929,931 0RH2202C622 22K 1/16W 5 D.R/TP
R912,932 0RH1001C622 1K 1/16W 5 D.R/TP
R919,976,978 0RH1002C622 10K 1/16W 5 D.R/TP
R920,921,960 0RH1003C622 100K 1/16W 5 D.R/TP
R933 0RH3303C622 330K 1/16W 5 D.R/TP
R934,935 0RH3902C622 39K 1/16W J D.R/TP
R936 0RH4703C622 470K 1/16W 5 D.R/TP
R966,967,968,969 0RH0102C622 10 1/16W 5 D.R/TP
R977 0RH4701C622 4.7K 1/16W 5 D.R/TP
R984,986 0RH6802C622 68K 1/16W 5 D.R/TP
R987,989,991,993 0RH0000C622 0 1/16W 5 D.R/TP
R994 0RH1002C622 10K 1/16W 5 D.R/TP
R997 0RH4702C622 47K 1/16W 5 D.R/TP
RESONATOR
X201 6212HA0202A CSACV20.00MXJ040-TC20 MURATA 2
X202 6212HA3452B CSACV34.57MXJ040-TC20 MURATA 3
X501 6212HA3382A CSACV33.86MX040-TC20 MURATA 33
SWITCH
SW303 6600HXF101A SPVF21001A ALPS . 5V 1MAV 4.65
TRANSISTOR
Q302,502,602,606 0TR144009AH DTC144EK CHIP ROHM-J
Q503,607,608 0TR144009AH DTC144EK CHIP ROHM-J
Q605 0TR144009AI DTA144EK CHIP ROHM-J
TRANSISTOR
Q302,502,602,606 0TR144009AH DTC144EK CHIP ROHM-J
Q503,607,608 0TR144009AH DTC144EK CHIP ROHM-J
Q605 0TR144009AI DTA144EK CHIP ROHM-J
- 91 -
Ref. No. Part No. Description
