Harman Kardon SIGNATURE 1.5 Technical Manual

12
Two Channel Amplifier Harman Kardon SIGNATURE 1.5
Signature 1.5 Electrical Parts List
POWER SWITCH/INDICATOR BOARD
Ref. # Part # Description Qty.
Fuses
FUSE1 A091-0007-0 5 x 20mm, 0.5A, 125V, FAST, UL, CSA 1
FUSE2 A091-0011-0 5 x 20mm, 10A, 125V, FAST, UL, CSA 1
Integrated Circuits
U1 A001-0005-0 LM393N, DUAL COMPARATOR, 8 PIN DI 1
U2 A001-2009-0 LM556CN DUAL TIMER 1
Transistors
Q1, 5, 6 A010-1013-0 MPSA56 PNP 80V 500MA TO-92 3
Q2, 3, 4, 7, 8 A010-0012-0 MPSA06 NPN 80V 500MA TO-92 5
Q29, 34 A010-0003-0 2SC3502-F, NPN, 200V, 100MA, TO-126 2
Q31, 36 A010-1003-0 2SA1380-F, PNP, 200V, 100MA, TO-126 2
Diodes
D1, 2, 3, 4, 7 A020-2106-0 1N4004, RECT, 1A, 150V, DO-41 5
D5, 6, 8, 9, 10, A020-1000-0 1N4148, RECT-FAST, 200MA, 100V, 4NS, 12
11, 12, 13, 14,
15, 16, 27
D17, 18, 19, 20, A025-0030-0 LED, BLUE, T1, .190, 470NM, SMALL 9
21, 22, 23, 24,
25
D26 A025-0012-0 LED, RED/GRN, 5MM, 630NM/560NM, 1
15MCD
D28 A020-0004-0 1N755A, ZENER, 7.5V, 500MW, DO-35 1
Capacitor
C1 A034-7103-0 CAP, CERAMIC DISK, .01m F, 10%, X-250V 1
C2, 3, 5, 9, 11 A030-2104-0 CAP, CERAMIC, AX, .1m F, 10%, 50V, X7R 5
C4 A031-0108-0 CAP, ELEC, RAD, 1000m F, -10%+50%, 16V 1
C6, 7, 8, 12 A031-0107-0 CAP, ELEC, RAD, 100m F, +/-20%, 4
16V, LOW L
C10 A031-0106-1 CAP, ELEC, RAD, 10m F, 20%, 25V, NP 1
C13, 14 A030-2103-0 CAP, CERAMIC, AX, .01m F, 10%, 50V, X7R 2
Resistors
R1, 2, 5, 9, A050-1003-0 RES, CARBON FILM, 10K OHM, 1/8W, 5% 9
10, 15, 18,
20, 22
R3, 4, 6, 19 A050-1004-0 RES, CARBON FILM, 100K OHM, 1/8W, 5% 4
R8, 13 A050-4703-0 RES, CARBON FILM, 47K OHM, 1/8W, 5% 2
R11, 12 A050-4702-0 RES, CARBON FILM, 4.7K OHM, 1/8W, 5% 2
R14 A050-0750-0 RES, CARBON FILM, 7.5 OHM, 1/8W, 5% 1
R17 A051-1502-0 RES, CARBON FILM, 1.5K OHM, 1/4W, 5% 1
R16 A051-2202-0 RES, CARBON FILM, 2.2K OHM, 1/4W, 5% 1
R21 A050-1005-0 RES, CARBON FILM, 1M OHM, 1/8W, 5% 1
Miscellaneous
A022-3001-0 THERMISTOR, 120 OHM, 2AMP, CL-90 1
A080-0002-A TRANS. STANDBY, 120V 10V@.35A 1
A080-0003-A TRANS. STANDBY, 230V 10V@.35A 1
K1, 2 A084-0001-0 RELAY SPNO 12VDC, 20A/125VAC, TV-10 2
S3 A090-0007-0 SWITCH, 8A/128A, 250V, PP, PCB 1
P1, 3, 4 A092-0010-0 FASTON, M, PC, .25" 3
P2 A092-0024-0 FASTON, M, PC, .187" 1
S4 A093-0049-0 HDR, 2MMX5, HORIZ, MALE, LOCK 1
T1 A080-0025-A TRANSFORMER SIG 1.5, 120VA 1
A095-0009-0 TRANSFORMER SIG 1.5, 230V 1
P5, 6 A093-0051-0 HDR, 2MMX2, VERT, MALE, LOCK 2
S2 A093-0151-0 HDR, 2MMX5, VERT, MALE, LOCKING 1
S1 A093-2005-0 HDR, 2MMX7, VERT, SHROUDED 1
A094-0004-0 FUSE CLIP, 5MM, P.C. MOUNT 2
HA206-0003-C Loaded Sig. 1.5 Power Switch Board 1
POWER AMP BOARD (120V)
Ref. # Part # Description Qty.
Transistors
Q1, 2, 39, 41, A010-0001-0 2SC3478, NPN, 180V, 100MA 6
44, 47
Q3, 42, 43 A010-1013-0 MPSA56 PNP 80V 500MA TO-92 3
Q4, 5, 8, 9, 12, A012-1003-0 2SA1962, PNP, 230V, 15A, 2-16C1A 12
13, 16, 17,
20, 21, 24,
25
Q6, 7, 10, 11, A012-0003-0 2SC5242, NPN, 230V, 15A, 2-16C1A 12
14, 15, 18,
19, 22, 23,
26, 27
Q28, 33 A012-1002-0 2SA1837 PNP 200V 1.5A 2-10R1A 2
Q30, 32, 35, 37 A012-0002-0 2SC4793 NPN 200V 1.5A 2-10R1A 4
Q38, 40, 45, A010-1002-0 2SA1376, PNP, 180V, 100MA, TO-92 6
46, 48, 49
Q50, 51, 52, 53 A010-0010-0 2SC2240, NPN, 120V, 100MA, TO-92 4
Q54, 55, 56, 57 A010-0012-0 MPSA06 NPN 80V 500MA TO-92 4
Diodes
BR1, 2 A023-0112-0 BRIDGE, 25A, 200V, VERT, PC, MP25S-02 2
D1, 2, 7, 10, A020-1000-0 1N4148, RECT-FAST, 200MA, 100V, 4NS 6
15, 16
D3, 4, 5, 6 A020-2106-0 1N4004, RECT, 1A, 150V, DO-41 4
D8, 9, 11, 12 A020-1022-0 BAV20, DIODE RECT, 200V 4
