Harman Kardon SUB-TS14 User Manual

Part numbe
r
Description
Qt
y
Reference Designato
r
PREAMP PCB
Miscellaneous
162-50332003 2 PIN 330mm RED 1 D209
174-0rca313v RCA JACK RCA-313G V/R/W 1 JK201
174-20810360g JACK SPK JK BP 8PIN 1 JK202
175-1b08v01 wire connector 8 PIN PITCH=2.0mm 1 W202
175-1c07v01 wire connector 7 PIN PITCH=2.5mm 1 M201
180-tms7210v SWITCH SLIDE 6PIN MS7210V 3 SW201,202,203
MAIN PCB
Resistors
110-14103j26 Resistor 10K 1/4W ±5% CF 26mm 3 R503,504,510
110-14222j26 Resistor 2.2K 1/4W ±5% CF 26mm 1 R511
110-14432j26 Resistor 4.3K 1/4W ±5% CF 26mm
1 R506
110-14472j26
Resistor 4.7K 1/4W ±5% CF 26mm
1 R505
110-16102j26
Resistor 1K 1/6W ±5% CF 26mm
1 R153
110-16103j26
Resistor 10K 1/6W ±5% CF 26mm
10 R128,130,149,150,305,306,308,311,314,319
110-16104j26
Resistor 100K 1/6W ±5% CF 26mm
3 R122,126,307
110-16153j26 Resistor 15K 1/6W ±5% CF 26mm 1 R107
110-16182j26 Resistor 1.8K 1/6W ±5% CF 26mm 1 R145
110-16203j26 Resistor 20K 1/6W ±5% CF 26mm 1 R309
110-16221j26 Resistor 220Ω1/6W ±5% CF 26mm 1 R144
110-16222j26 Resistor 2.2K 1/6W ±5% CF 26mm 1 R102
110-16223j26 Resistor 22K 1/6W ±5% CF 26mm 1 R316
110-16333j26 Resistor 33K 1/6W ±5% CF 26mm 1 R310
110-16393j26 Resistor 39K 1/6W ±5% CF 26mm 1 R151
110-16434j26 Resistor 430K 1/6W ±5% CF 26mm 1 R312
110-16473j26 Resistor 47K 1/6W ±5% CF 26mm 2 R106,129
110-16474j26 Resistor 470K 1/6W ±5% CF 26mm 1 R127
110-16562j26 Resistor 5.6K 1/6W ±5% CF 26mm 1 R152
110-16621j26 Resistor 620Ω1/6W ± 5% CF 26mm 1 R160
110-16751j26 Resistor 750Ω1/6W ± 5% CF 26mm 1 R315
110-16755j26 Resistor 7.5M 1/6W ± 5% CF 26mm 1 R313
116-161002f26 metal film Resistor 10K 1/6w ± 1% MF 26mm 2 R301,303
116-161202f26 metal film Resistor 12.0K 1/6w ± 1% MF 26mm 1 R302
116-162200f26 metal film Resistor 220Ω1/6w ± 1% MF 26mm 1 R317
116-162202f26 metal film Resistor 22.0K 1/6w ± 1% MF 26mm 1 R318
110-20332jk3 Resistor 3.3K 2W ±5% 7.5m 1 R134
113-50s68j00 cement Resistor 0.068Ω5w ± 5% 1 R147
116-201001jk3x metal film Resistor 1.00K 2w ± 5% MF 7.5mm 1 R148
116-304700jk2x metal film Resistor 470Ω3w ± 5% MF 10mm 2 R501,502
Capacitors
130-2f104z503 disc capacitor 0.1U 50V ±10% 6 R107,117,122,144,320,322
130-sl101k503 disc capacitor 100P 50V SL ± 10% 3 C302,303,306
132-103j503 mylar capacitor 0.01U 50V ±5% 2 C305,317
132-103ja03 mylar capacitor 0.01uF 100V ±5% 2 C103,104
132-104ja03 mylar capacitor 0.01uF 100V ±5% 3 C123,503,504
132-273ja03 mylar capacitor 0.027uF 100V ±5% 1 C143
SUB-TS14
harman/kardon
20
