SUB-TS14 120V Electrical parts list
Part numbe
r
Description
Qt
y
Reference Designato
r
PREAMP PCB
Resistors
110-12472j52 Resistor 4.7K 1/2W ±5% CF 52mm 2 R201,202
110-16102j26 Resistor 1K 1/6W ±5% CF 26mm 4 R213,214,215,254
110-16103j26 Resistor 10K 1/6W ±5% CF 26mm 18
R209,212,216,217,218,220,221,222,225,228,229,230,
232,235,240,248,260,270
110-16104j26
Resistor 100K 1/6W ±5% CF 26mm
3 R231,263,266
110-16105j26
Resistor 1M 1/6W ±5% CF 26mm
1 R259
110-16122j26
Resistor 1.2K 1/6W ±5% CF 26mm
1 R265
110-16134j26
Resistor 130K 1/6W ±5% CF 26mm
1 R233
110-16151j26 Resistor 150Ω 1/6W ±5% CF 26mm 1 R253
110-16154j26 Resistor 150K 1/6W ±5% CF 26mm 1 R252
110-16183j26 Resistor 18K 1/6W ±5% CF 26mm 1 R262
110-16203j26 Resistor 20K 1/6W ±5% CF 26mm 2 R237,238
110-16205j26 Resistor 2M 1/6W ±5% CF 26mm 1 R257
110-16223j26 Resistor 22K 1/6W ±5% CF 26mm 3 R247,255,256
110-16303j26 Resistor 30K 1/6W ±5% CF 26mm 2 R223,224
110-16472j26 Resistor 4.7K 1/6W ±5% CF 26mm 3 R200,207,258
110-16473j26 Resistor 47K 1/6W ±5% CF 26mm 5 R219,249,250,251,264
110-16512j26 Resistor 5.1K 1/6W ±5% CF 26mm 2 R210,211
110-16622j26 Resistor 6.2K 1/6W ± 5% CF 26mm 1 R234
110-16913j26 Resistor 91K 1/6W ± 5% CF 26mm 4 R203,204,205,206
115-h503a102 variable Resistor RV16AE-20B2-15K-A54-104(A50K) 1 VR201
Capacitors
129-a154j633 metallize capacitor 0.15U 63V ±5% MSC 2 C221,222
129-a224j633 metallize capacitor 0.22uF 63V ±5% MSC 1 C218
130-2b221k503 disc capacitor 220P 50V ±10% 12 C200,204,205,207,208,210,21,212,214,220,230,237
130-2b470k503 disc capacitor 47P 50V ±10% 1 C229
130-2f104z503 disc capacitor 0.1U 50V +80/-20% 8 C232,242,244,245,246,252,254,256
132-183j503 mylar capacitor 0.018uF 50V ±5% 1 C223
132-223ja03 mylar capacitor 0.022uF 100V ±5% 1 C215
132-473j503 mylar capacitor 0.047U 50V ±5% 1 C224
132-563j503 mylar capacitor 0.056U 50V ±5% 1 C216
132-823j503 mylar capacitor 0.082U 50V ±5% 1 C217
135-3105m50 electrolytic 1U 50V ±20% 1 C228
135-3106m50 electrolytic 10uF 50V ±20% 10 C201,202,206,213,219,231,241,243,251,253
135-3107m16 electrolytic 100uF 16V ±20% 1 C234
135-3226m50 electrolytic 22U 50V ±20% 1 C225
135-3227m16 electrolytic 220U 16V ±20% 1 C233
Semiconductors
192-027c1815gr IC 2SC1815GR NPN 3 Q201,206, 207,208
197-131n4148 diode 1N4148 26mm 11 D201,202,203,204,205,206,207,208,214,215,216
199-15000335 zener diode 3.3V 1/2W 52mm 1 D213
190-06m4558d I.C. OPA 4558D DUAL OP-AMP 1 U203
190-16tl074cn I.C TL074CN ST QUAD OP-AMP 2 U201,202
SUB-TS14
harman/kardon
19
