Harman Kardon SUB-TS14 User Manual

HKTS 14 Sub 200W Powered Sub/ Plate Amp
LINE VOLTAGE Yes/N
o
Hi/Lo Lin
e
Nom. Uni
t
Note
s
US 120vac/60Hz Yes 108-132 120 Vrms
Normal Operatio
n
Parameter
Nonimal
Specification
Unit
QA Test
Limits
Conditions
Notes
Amp Sectio
n
Type (Class AB, D, other) D n/a
n/a
Bridge type amplifier, None of the
speaker terminals must be
connected to system GND at any
Load Impedance (speaker) 3.5 Ohms
n/a
Nominal
Rated Output Power 200 Watts
150
50 - 250 Hz, 1 input driven, limiter off
THD @ Rated Power 0.08 %
0.1
22k filter
THD @ 1 Watt 0.15 %
0.5
22k filter
DC Offset 5 mV-DC
20
@ Speaker Outputs
Damping factor 16 n/a
10
Measured at amplifier board
Measured at the speaker at speak
e
output terminals on the amp board.
Input Sensitivit
y
Input Frequency 50 Hz
n/a
Nominal Freq.
Line (L&R) Input 220 mVrms
154 - 308
To Rated Power
Single input drive
n
SUB (LFE) Input 125 mVrms
87 - 175
To Rated Power
SUB (LFE) input driven onl
y
Speaker/Hi Level Input 3.4 Vrms
2.4 - 4.8
To Rated Power
(20 dB below Line In), Single input
Hi Level Max. Input Voltag
e
32 Vrms
30
Nominal Freq., Min. Volume
Signal to Noise Rati
o
SNR-A-Weighted 85 dB
82
relative to rated power
A
-Weighting filte
r
SNR-unweighted 62 dB
59
relative to rated power
22k filte
r
SNR rel. 1W-unweighted 64 dB
59
relative to 1W Output
22k filte
r
Residual Noise Floor 1.2 mVrms
3.0
Volume @max, using RMS
reading DMM/VOM (or A/P)
Residual Noise Floor 0.8 mVrms
2.0
Volume @max, w/ A/P Swept
Bandpass Measurement (Line
freq.+ harmonics)
Input Impedanc
e
Line Input (L, R,LFE) 10K ohms
n/a
Nominal
Speaker/Hi Level Input 4.7K ohms
n/a
Nominal
Filter
s
L&R Fixed Low-Pass Filter 160 Hz
140 - 180
@ -6dB ref. 100Hz
3rd order fixe
d
SUB (LFE) Low pass Filter 270 Hz
240 - 300
@ -3dB ref. 100Hz
2nd order fixe
d
Subsonic filter (HPF) 3rd Order 25 Hz
22 - 28
@ -3dB ref. 30Hz
3rd order fixe
d
Limiter
THD at Max. Output Power
2.0 %
5.0
Features
Auto - On -Off Selection Switch YES
functional Refer to ATO sectio
n
Phase Switch 0-180 deg
functional
Filter On/Off Switch YES
functional
Volume Pot Taper (Lin/Log) LOG
functional
A
Tape
r
Speaker Out YES
functional Binding post connector L&
R
2-Color LED power indicator YES
functional Blue: On, Amber: Stand-b
y
Power Switch YES
functional
Fuse Holder YES
functional
Input Configuratio
n
Line In (L,R) YES
functional Dual RCA jack
SUB (LFE) YES
functional RCA jack
Speaker/Hi Level In YES
functional Binding post connector L&
R
Signal Sensing (ATO
)
Auto-Turn-On (yes/no) YES
functional
Auto - on selection switch in Auto
ATO Input test frequency 50 Hz
n/a
"
ATO Level Line & SUB Input 4.0 mV
2.0 - 6.0
"
ATO Level Speaker in 35 mV
20 - 50
"
ATO Turn-on time 0.9 sec.
functional
A
mp connected and AC on, then
input signal applied
ATO Turn-OFF Time 12 minutes
5 - 17
Time before muting, after signal is
removed
SUB-TS14
harman/kardon
2
