Part numbe
r
Description
Qt
y
Reference Designato
r
Power Amp Class D Module part# 012-7500-00022 RECOMMENDED: REPLACE ENTIRE MODULE
118-12064701j SMD Resistor 4.70K 1206 5% 3 R1,5,12
118-12064702j SMD Resistor 47.0K 1206 5% 1 R17
118-12064704j SMD Resistor 4.70M 1206 5% 1 R4
118-120647r0j SMD Resistor 47.0Ω 1206 5% 2 R20,21
Capacitors
141-c0101k50 SMD Capacitor 100pF 50V 10% 1206 NPO 1 C4
141-c0220k50 SMD Capacitor 22pF 50V 10% 1206 SMT NPO 1 C5
141-c0561k50 SMD Capacitor 560pF 50V 10% 1206 NPO 1 C6
141-c5104m50 SMD Capacitor 1206 Y5V 0.1uF 50V ± 20% 8 C2,3,7,8,9,10,11,15
141-c7223k50 SMD Capacitor 0.022uF 50V 10% 1206 X7R 1 C13
141-d7104ka0 SMD Capacitor 0.1uF 100V 10% 1210 X7R 5 C12,14,18,19,20
141-d7104kb5 SMD Capacitor 0.1uF 250V 10% 1210 X7R 1 C1
Semiconductors
192-232irf9640 transistor FET IRF9640 IR P-CH TO-220 1 Q10
192-233irf640 transistor FET IRF640 IR N-CH TO-220 1 Q11
190-16tl072dts SMD I.C. TL072CDT SGS THOMSON 1 IC1
192-09124126qs SMD transistor 2SC2412K-T146Q/R 3 Q1,4,5
192-09139066rs SMD transistor 2SC3906K-T146R ROHM 2 Q2,8
192-09210376qs SMD transistor 2SA1037K-T146Q/R ROHM 2 Q7,9
192-09215146rs SMD transistor 2SC1514K-T146R ROHM 2 Q3,6
197-03rls4148s SMD diode RLS4148-TE11 ROHM 6 D1,2,3,4,5,6
199-15000563s SMD zener diode 5.6V 5% PHILIPS BZX84-C5V6 2 Z1,2
199-15001203s SMD zener diode 12V 5% PHILIPS BZX84-C12 2 Z5,6
199-15001503s SMD zener diode 15V 5% PHILIPS BZX84-C15 1 Z3,4
Miscellaneous
122-14121m4191 Ferrite core LS-A6206-ST EFD-30 1 L1
122-14350j4180 choke coll 35uH Ferrite Core 25 1 L2
128-e106ma01 non-polar 10uF 100V 20% 2 C16,17
175-9f40hr2 wire connector 40PIN PITCH=2.54mm HR2*40 0.2
MISCELLANEOUS/MECHANICAL
150-r4055903 power transformer TT0900304490 1 T501
152-u602015 line cord SVT FT-2 6FT 1
154-k31505t0 fuse3.15A 250V 30mm UL/CSA 1 F501
155-63032i fuse holder HTB-32I 3mm UL/CSA 1 F501
162-10082007 wire RED 18AWG 80mm 8mm#1015 1
162-5050d003 wire ul11015 500mm 1 M100
162-10152001 wire ul1617 AWG22 150mm RED 1
163-11009 wire tie 100mm 2
176-Wwjcel wire Connector & Base CE-1 1
180-pbr12c11s Power switch PUSH BR12C11S 1 SW501
193-201815t2 insulator 2 for Q10,Q11,
302-AL-00373-0 Alum. Back panel
306-ABS-00004 REAR CABINET 268*213*102 A.B.S UL
311-ABS-00028 Knob 46077-W P.V.C.
SUB-TS14
harman/kardon
22
