Harman Accentra Pellet Insert User Manual

10
3-90-00674R28_12/13
Installation
How to Reduce the Weight for Installation, cont'd
• Liftuponthe2bottomcornersofthemedallionuntilitis
higherthanthetopoftheameguide.Fig.14
• Pullthebottomedgeofthemedallionfrontapproximately
1inch.
• Pulldownwardonthecornersofthemedallionuntilthetop
isreleasedfromthe2retainersthatkeepthetopaligned
wheninplace.
Note:Theheatexchangercoverswilltilttothefrontwhen
thecentermedallionisremoved.
• Remove the heat exchanger cover by lifting it upward
about1/2inchandmovethebottomedgefrontuntilitsits
atonthereboxbottom.
• Rotate the edge of the heat exchanger closest to the
burnpotuntilitisinfrontoftheburnpot.
• Tipthetopoftheheatexchangertowardthemiddleof
theopeninguntilitcanbeliftedupandout.
Flame guide
Burn Pot
3
rd
: DOWN
1
st
:UP
2
nd
: OUT
Fig.14
Lifting tab
Fig.15
Removethecastsidepanelsbyliftingthemupwardoffofthe
hingepins.SeeFig.13.
Removing the Center Medallion
Removing the Heat Exchanger Covers
Laseredhingepinpivot-
ingpoint
Upanddownclearance
adjustmentslots.
Castside
panelhinge
Fig.13
2. Removethedoorbyswingingitopenapproximately90
°

andliftitupwarduntilitclearsthehingepins.
3. Removetheashpan
4. Removethe(4)internalpiecesofcastiron.SeeFig.14
and15.
