Harman Accentra Pellet Insert User Manual

22
3-90-00674R28_12/13
Besuretouseapprovedpelletvent pipe wall and ceiling
pass-throughttingstogothroughcombustiblewallsand
ceilings.Besuretouseastartingcollartoattachtheventing
systemtothestove.Thestartingcollarmustbesecuredto
theuestubwithatleastthreescrews,andsealedwithhigh
tempsiliconecaulking.
4" stainless steel ex vent piping is only allowed for use
in masonry replaces and chimneys or factory built wood
burningreplaceswithclassAmetalchimneys.
Pellet venting pipe (also known as Type L or PL vent) is
constructedoftwolayerswithairspacebetweenthelayers.
Thisairspaceactsasaninsulatorandreducestheoutside
surfacetemperaturetoallowaclearancetocombustiblesof
only3inches.Thesectionsofpipelocktogethertoforman
airtightsealinmostcases;however,insomecasesaperfect
sealisnotachieved.Forthisreasonandthefactthatthe
AccentraInsertoperateswithapositiveventpressure,we
specifythatthejointsalsobesealedwithsilicone.
Wherepassingthroughanexteriorwallorroof,besuretouse
theappropriatepass-throughdeviceprovidinganadequate
vaporbarrier.Ventingmanufacturersgenerallyprovidethese
pas-throughdevices.
Venting
100%OutsideAirKit
Fig.47
100% Outside Air Kit
# 1-00-674080
Designed for 3" ex pipe
1/8" Fiberglass Gasket
2 3/8" ID Flex Pipe
1/2" Silicone Gasket
Intake Box
Vent Congurations:
To reduce probability of reverse drafting during shut-
down conditions, Hearth & Home Technologies strongly
recommends:
• Installingthepelletventwithaminimumverticalrunofve
feet,preferablyterminatingabovetheroofline.
• Installingtheoutsideairintakeatleastfourfeetbelowtheventtermination.
Topreventsootdamagetoexteriorwallsofthehouseandtopreventre-entryofsootorashintothehouse:
• Maintainspeciedclearancestowindows,doors,andairinlets,includingairconditioners.
• Ventsshouldnotbeplacedbelowventilatedsofts.Runtheventabovetheroof.
• Avoidventingintoalcovelocations.
• Ventsshouldnotterminateunderoverhangs,decksorontocoveredporches.
• Maintainminimumclearanceof12inchesfromtheventterminationtotheexteriorwall.Ifyouseedepositsdeveloping
onthewall,youmayneedtoextendthisdistancetoaccommodateyourinstallationconditions.
Hearth & Home Technologies assumes no responsibility for, nor does the warranty extend to, smoke damage caused
by reverse drafting of pellet appliances under shut-down or power failure conditions.
Vent Pipe
The outside air kit consists of a ue stub pipe, berglass
gasket,siliconegasket,intakeboxandasectionofexpipe.
SeeFig.47.
Anadjustablechimneyintakeextension,part#1-00-674104
isavailabletobeusedonmasonrychimneysonly.SeeFig.
48.
Additionalinformationanddiagramscanbefoundonpages
23thru27,underventing.
Toinstalloutsideair,usekitpartnumber1-10-674080.Follow
theinstallationinstructionsprovidedwiththekit.
Outside Air
Chimney cap and flex termination with
flashing plate (by installer) THIS CAP
MUST BE Stainless Steel
With the intake assenbly anchored into
place, finish the 4” SS flex liner and cap
(by installer) by screwing the cap’s flashing
plate to the top of the intake assenbly.
A waterproofing sealant can be used to
seal the corners and irregularities in the top
of the masonry chimney.
After adjusting the intake assembly
for the flue size, secure the
assembly to the top of the chimney
with some form of anchors or
screws.
Masonry Flue Liner
Masonry Chimney
Fig.48
Adjustable Chimney Intake Extension Part # 1-00-674104
18 1/8”
18 1/8”
18”
18”
22 1/8”
18”
22 1/8”
4”
6”
1”
Harman® SS Chimney Top Intake Assembly
