6
3-90-00674R28_12/13
Manual Start Up
Igniter Switch to "MANUAL" (down position) Make
suretheunitispluggedintoa120VAC,60Hzelectrical
source.Thepowerlightshouldbetheonlylightlit.
NOTE: Be sure there is no fuel or other combustibles in
the ash pan prior to lighting.
1.TurnFEEDADJUSTERtodesiredfeedrate.No.4isgood
formostpellets.
2.Turnthe MODE SELECTOR to “OFF” and then to the
desired mode. This will reset control and start the
combustionmotor.
3.TurntheTEMPERATUREDIALtothedesiredsetting.
4.Cleanburnpotwithscraperifnecessary.
5.Fillburnpotwithpellets,onlylevelwithfrontedge.(Do
NotOverFill).
6.Addstartinggelontopofthepellets.Stirgelintopellets
forfastlighting.
7.Light starting gel with a match, and close the door.
Operation will begin when the re reaches the proper
temperature.
8.Fillhopperwithpelletsandremoveashesasrequired.
Storefuelinadryarea,awayfromallignitionsourcesand
outside all limits of the stove's clearance requirements to
combustibles.Donotstore the fuelwereitinterferes with
therefuelingofthestoveoremptyingofashes.Donotstore
any ashes removed from the stove near the fuel or other
combustiblematerials.
Fig.7
1"
See Note 7.
WARNING
NEVER USE GASOLINE, GASOLINE-TYPE LANTERN
FUEL, KEROSENE, CHARCOAL LIGHTER FLUID, OR
SIMILAR LIQUIDS TO START OR 'FRESHEN UP' A FIRE
IN THIS HEATER. KEEP ALL SUCH LIQUIDS WELL
AWAY FROM THE HEATER WHILE IN USE.
Fig.5
WARNING
BURNING GARBAGE, USE OF IMPROPER FUELS,
FIRE STARTERS OR ALTERING THE STOVE FOR
HIGHER HEAT OUTPUT MAY CAUSE DAMAGE TO THE
STOVE AND COULD RESULT IN A HOUSE FIRE. USE
ONLY APPROVED FUELS AND FOLLOW ONLY THESE
OPERATION GUIDELINES.
Starting First Fire
Fig.6
1. Fines are small pieces of broken pellets (sawdust). Fines do
not ow easily and often build up on the hopper funnel bottom
angles. These nes can be pushed into the feeder opening and
then ll the hopper with pellets. As the system works, they will
be burned.
2. The "TEST" cycle will operate the feeder motor for exactly one
minute. Turning to "TEST" again and again may load too much
fuel into the burn pot causing excessive smoke on start-up.
3. The rebox low pressure switch will not allow the auger motor
or the igniter element to operate if the view door or the hopper
lid are open.
4. Adjust Feed Rate. If this is your rst re or you are trying different
pellets, set the feed adjuster to #4, Fig. 5. This is a conservative
number and will probably need to be increased. After you know
a feed rate setting that works well, use that setting. Remember,
if your feed rate is too high you may waste fuel.
5. This is usually a weekly maintenance procedure. Cleaning the
burn pot with the scraper with a small amount of new fuel in the
bottom is not a problem. First, scrape the ashes off the front of
the burn pot into the ash pan. Then scrape the holed surface
downward into the burn pot. When the stove is ignited these
scrapings will be pushed out by the feeder.
6. The ash pan can hold the ashes from approximately 1 ton of
premium fuel. This means the ashes will only need to be emptied
a few times a year.
7. Setting the feed adjuster # for maximum burn: With the unit
burning in "AUTO", turn to "Stove Mode" and put the fan on
"H". Set the Temperature Dial to #7. Allow the unit to burn for
about 30 minutes and check ash on front of burn pot. Fig. 9. If
the ash line is larger than 1", turn the feed adjuster from #4 to
#5. Allow another 30 minutes of burn time and check again. If
, at #6 setting, a 1" or less ash bed is not obtainable, it is not
a problem. The 1" ash bed is only at maximum burn rate and
during normal operation, the ash bed will be larger.
To Next Page
