Harman Accentra Pellet Insert User Manual

9
3-90-00674R28_12/13
TopandLidAssembly
Center
Medallion
FlameGuide
Heat
Exchanger
Cover
AshPan
(2)SpringLatches
(Oneoneachside)
Internal
Cast Iron
(4) pieces
MountingShell
NOTICE:Whenremovingthetopandlidassembly,
rstremovethehopperlidpositionswitchfromits
mounting bracket. Loosen the switch retainer nut,
andallowtheswitchtodropoutofthebracket.Leave
the bracket in place.
Fig.11
Installation
1.Removethetop/lidassemblyandsidepanels.
Note: Removal of the cast hopper lid itself is NOT
necessary or recommended.
Note:Thehopperlidmustbeinthe"OPEN"positionbefore
thetop/lidassemblycanbeliftedoff or reinstalled on the
stovebody.
Thereare(4)1/4-20x1/2"angeheadboltssecuringthe
top/lidassemblytothestovebody.Theycanberemoved
fromtheundersidewitha3/8"socket.
The cast top and lid assembly bolt down bars:
Oneachsideofthestovebody,underneaththecasttop,
are(2)1/4"angeheadbolts.SeeFig.12.
Theseboltspullthecasttopandlidassemblydownontothe
hoppergaskettosealthehopper.
Theyalsoallowforasmallamountoffronttobackadjustment
foralignmentofthetopintothewingpockets.
ProtectorAngles: These angles are designed to
protecttheblowermotorfromdamagewhenplaced
onaatsurface.Becarefulwhereandhowthestove
bodyishandled.
Be careful not
to damage the
distribution blower
located under the
insert. There are
guardsonbothsides
ofthemotortoallow
theinserttorestona
atsurface,however,
extracareshouldbe
taken.
DistributionBlower
Bolts require a
3/8" socket.
(View looking up under the cast top.)
Top bolt down bar
Fig.10
Fig.12
How to Reduce the Weight for Installation
