Harman Accentra Pellet Insert User Manual

11
3-90-00674R28_12/13
Installation
IMPORTANT: Themountingframe/surroundassemblyand
uepipingisthemostcriticalpartoftheinstallationandmust
bedonecorrectlyandinstalledsecurely.
1. Choosethechimneycongurationthatisbestsuitedfor
theinstallation.Seeventingsection.Page21
Note:If100%outsideairisdesiredorrequired,theoutside
airoptionwillneedtobeinstalledonthestovesbody.(See
instructionsincludedwithoutsideairkit(part#1-00-674080.)
SeePage22.
2. Makesuretheunitwilltintothereplaceopening.When
installinginsmallerreplaces,testtthemountingframe
intotherebox.Note:Theunitoverhangstotherear.See
Fig.17
3. Installing the 3 piece cast surround:Installtheleftand
rightcastsidestothemountingframeusingthe1/4-20x
3/8boltssupplied.Install(4)1/4-20x3/4"setscrewsinto
thetopwing.Theninstallthetopwingontotheframeusing
the(4)1/4-20nuts.Theleftandrightsideshouldbedone
beforethecentersectionisinstalled.Makesurethebolts
areloose.Donotremovethesidepanelhinges.Theleft
andrightsidewingsshouldbestandingupalignedwith
thesideofthemountingframeandslidinwardtowards
thecenter.Note:Thewingsmountontherearsidebelow
thenotchandonthefrontsideabovethenotch.SeeFig.
16&18.Slidethecastashlipontotheframeandcheck
tomakesureitcangoagainsttheropedframerailsand
tsintothepocketsontheleftandrightcastsides.See
Fig.19.
Installthecentersection.
4. If the wing extension is required, it should be installed
next.
Beginning Installation
Fig.18
Cast in front of
the frame. Use
(1)1/4-20 x 3/8
flange bolt from
therear.
Cast behind the
mounting frame
flange. Use (2)
1/4-20x5/8ange
bolts and nuts
with bolts from
thefront.
NOTE:Thestovebodyextendsthroughthemountingframein
therearapproximately2".
Fig.17
Slidetheashlipcasting
intotheframe,making
certain the ash lip is
sittingonthesliderails
on either side. With
the ash lip in place,
adjust the surround
sides so there is an
even gap where the
ash lip extends into
thesurroundsideand
tighten.
Fig.19
3"OutsideAirstartercollar
Fig.16
Notch
Ashlipsliderails
