Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/1525 3-90-08326c
Service Parts
Accentra-Cast
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide model number and
serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
5 Top Bolt Down Cover Qty 2 req 2-00-247185L
6 Top Bolt Down Cover Gasket Pkg of 2 1-00-07383
7 Differential Switch 3-20-6866
Y
8
Z Bracket, Right 2-00-247119B
9 Z Bracket, Left 2-00-247139B
10 Glass Hopper Lid 3-40-247100
Y
Gasket,Glass Hopper Lid
Pre 11340 3-44-247300
Y
Post 11340 1-00-375501
Y
Gold Plated Knob (Hopper) 1-00-02000
Brushed Chrome Knob 1-00-02000-8
Hinge Plate Qty 2 req 2-00-06695L
Hopper Ball Spring Plunger (Threaded) Pkg of 3 3-31-5500-3
Hopper Lid Ball Spring Mount Bracket Pre 11340 2-00-247116
Hopper Lid Glass Assembly w/Gasket Pre 11340 1-10-247100
Y
Hopper Hinge Assembly (Qty 2 req) Pre 11340 1-10-247151
Y
Hopper Lid Hinge Post 11340 2-00-06694
Hopper Lid Spring Latch Pre 11340 1-00-247167
Hopper Lid Latch (Set OF 2) Post 11340 1-00-0669697
Y
Push Retainer, 5/16" Pkg of 100 3-31-94807-100
Screw Post 1/4"/ Washers (Hopper Lid) 20 Sets 1-00-129004
Y
11 Cast Top Painted 4-00-247236S
12 Cast Side Plate Left Painted 4-00-247106D
13 Air Jacket Top 2-00-247219B
14 Cast Combustion Housing 4-00-247104
15 Comb Intake Assembly 1-10-247124W
Y
16 Comb Manifold Latch Left 2-00-247126-1S
17 Cast Heat Exchanger 4-00-247103
18 Cast Accordion Cover Qty 2 req 3-00-247105
Y
19 Burn Pot Assembly 1-10-08736
Y
Clean out Cover 2 Sets 1-00-06623
Y
Flame Guide 3-00-08534
Y
Igniter
3-20-677200
Y
Pkg of 10 1-00-677200
Y
Igniter Cradle, Holder & Flat Bottom 3 Sets 1-00-06620
Y
Thumb Screw Pkg of 10 3-31-782108-10
Y
Additional service parts on following page.
