Harman Accentra Owner's Manual

Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/1526 3-90-08326c
Service Parts
Accentra-Cast
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide model number and
serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
20 Door Latch Assembly
Latch Bar 2-00-247175L
Dowel Pin Retainer 2-00-247187L
Shoulder Screw, 5/16" shldr x 1/4" x 1/4"-20 Thread Alloy Steel
Pkg of 5 3-30-1105-5
Y
Dowel Pin 1/4" x 1-1/4" Pkg of 15 3-30-2017-15
21 Door Handle Assembly
Door Handle - Painted 3-00-247112P
Y
Door Only
Painted 4-00-247109P
Y
Majolica Brown 4-00-247109-14S
Y
Wooden Handle w/ Hardware 2 Sets 1-00-00247
Y
22 Cast Door w/Rope and Grill 1-10-247109A
Door Rope 1-00-00888
Y
23 Cast Air Grill 3-00-247114
24 Door Glass with Gasket 1-00-777000
Y
Glass Rope 1-00-2312
Y
25 Glass Retainer Qty 2 req 2-00-247156B
26 Cast Front Frame 4-00-247108C
27 Ash Pan Weldment 1-10-247160
Y
28 Accordion Cover Latch w/Hardware 1-00-247131
29 Cast Base Plate Painted 4-00-247110D
30
Distribution Blower Plate 2-00-247117S
31 Cast Hinge Qty 2 req 4-00-247113
32 Cast Side Plate Right Painted 4-00-247107D
33 Distribution Blower 1-00-29145
Y
Wire Kit (Needed for Bay Motor to EBM)
No longer available
1-00-29045
34 Combustion Manifold Latch, Right 2-00-247126-2S
35 Air Jacket BTM Weldment 1-10-247121S
36 Combustion Blower 3-21-08639
Y
Blower Mounting Screws (Pkg of 100)
Commonly required
for Combustion
Blower replacement
1-00-53483212
Combustion Blower Gasket 1-00-07383
Fan Blade, Single Paddle 5" (Comb Blower) 3-20-40985
Y
37
Feeder Assemblies
Pre 008400001
Parts diagram on
following pages
38 Post 008400001
Additional service parts on following page.
