Harman C411 L - Technical Data; Technical Specifications

C411
III
MANUALC411
III
MANUAL32 33
TEcHNIcAL dATA TEcHNIcAL dATA
7 Technical data
Type: pre-polarized condenser transducer
Polar pattern: Figure 8
Frequency range: 10 – 18,000 Hz
Sensitivity: 1 mV/ms-2 (vibration pickup)
Impedance at 1,000 Hz: 200 Ω, unbalanced
Recommended load
impedance:
≥1,000 ohms
Max. SPL for 1%/3% THD: 96 dB / 103 dB
Powering: C411
III
PP: 9 to 52 V universal phantom
power
C411
III
L: B 29 L battery power supply,
MPA V L phantom adapter,
AKG WMS bodypack transmitters
Current consumption: approx. 2.2 mA
Cable length/Connector: C411
III
PP: 3 m (10 ft.) / 3-pin male XLR
C411
III
L: 1.5 m (5 ft.) / 3-pin mini XLR
Finish: matte black
Dimensions: 27 x 14 x 9.5 mm (1 x 0.6 x 0.4 in.).
Net/shipping weight: C411
III
PP: 98 g (3.5 oz.) / 225 g (8 oz.)
C411
III
L: 18 g (0.6 oz.) / 150 g (5.3 oz.)
Frequency responce C411
III
Polar Diagram C411
III
