JBL PROFESSIONAL
LOUDSPEAKERS AND LOUDSPEAKER SYSTEM
Q.A. CODES
28
July 1, 2004
Page 2
Q.A.
CODE
DESCRIPTION OF DEFECT WARRANTY
STATUS
Q.A.
CODE
DESCRIPTION OF DEFECT WARRANTY
STATUS
6.5 External Damage to the frame resulting in
distortion of its structural members
OUT
9.0 Horn failures – (Specify)
6.6 External Damage - Magnet Assembly OUT 9.1
Appearance - Color or Scratches – (Specify)
IN
6.7 External Damage - Cone and Dome OUT 9.2 Broken Horns - Flanges IN
6.8 External Damage -Frame, Cone & Magnet OUT 9.3 Broken Horns - Throat IN
6.9 External Damage - Frame, Cone
Assembly
OUT
6.10 External Damage – No Salvageable Parts OUT 11.0
MISCELLANEOUS
6.11 External Damage - Diaphragm OUT
6.12 External Damage - Broken Terminal OUT 11.1 Not JBL Cone/Coil Assembly/Diaphragm OUT
6.13 External Damage - Broken Grille OUT 11.2 Missing Cone/Coil Assembly OUT
6.14 External Damage - Hardware OUT 11.3 Missing Diaphragm Assembly OUT
11.4 Poor Field Installation * OUT
7.1
Buzzing - Unclassified (Specify) OUT
11.5 Returned Incomplete OUT
7.2 Buzzing - Diaphragm Overdriven
(indicate damage to diaphragm)
OUT
12.0 Hardware – (Specify)
IN
8.0 Systems Failures – (Specify)
IN 12.1 Not to Specifications IN
8.1
Appearance - (Specify)
IN 12.2 Missing Hardware IN
8.2 Wrong or Missing Component IN
8.3 Broken Component - Corners IN 13.0
Accessories
IN
8.4 Broken Component - Grilles IN 13.1 Defective Bag/Cover IN
8.5 Broken Component - Handles IN
8.6 Broken Component - 1/4 “ Phone Jack IN
8.7 Broken Component - Network Switches OUT
*INDICATE DAMAGE TO
8.8 Broken Component - Networks IN
CONE/COIL ASSEMBLY
8.9 Burned Network OUT
8.10 Packaging Problem IN
8.11 Open-Fuse/Lamp OUT
8.12 Defective Cabinet - Improperly assembled IN
8.13 Defective Cabinet - Physical Damage OUT
8.14 Defective Cabinet - Delaminating
Duraflex / Carpeting
IN
8.15 Hooked Up Improperly IN
8.16 Broken Component - Dolly IN
8.18 Open - Cold Solder on network/connector IN
