16
EON618S SPECIFICATIONS
Bottom View Front View Left View
Rear View
System Specification
System Type: Self powered 18”, subwoofer
Maximum SPL Output: 134 dB
Frequency Range (-10 dB): 31 Hz - 150Hz
Frequency Response (±3 dB): 42 Hz - 150Hz
EQ: 3 Parametric EQ’s, High and Low Shelf (Available via Bluetooth app only)
Amplification
Amplifier Design: High Efficiency Class D
System Power Rating: 1000W Peak, 500W Continuous
Input Impedance: 22K ohms (Balanced)
Line Input Gain: 0 + 36 dBu
Mic Input Gain: -
Connectors: 2 x Balanced XLR-1/4” combination inputs; 2 x male XLR loop thru out
LED Indicators: Front Power, Rear Power , Bluetooth, EQ+, Preset, Signal, Limit
Cooling: Passively Cooled (No Fan)
AC Power Input: 100-120VAC 50/60Hz; 220-240VAC 50/60Hz
AC Power Consumption (120VAC): 1/8th Power – 1.14A (Max), 1/4th Power – 1.71A (Max), 1/3rd Power – 2.03A (Max)
Speaker Specification
LF Driver: JBL 618H 457mm (18”) woofer with 2” voice coil
Crossover Frequency: Selectable; 80 Hz, 100 hz, or 120 Hz
Enclosure
Material: Duraflex coated wooden enclosure
Suspension / Mounting: M20 Threaded Pole Cup
Handles: 2
Finish: Black Duraflex
Grille: Powder coated perforated steel with acoustically transparent screen backing
Dimensions (H x W x D): 582mm x 668mm x 645mm (22.9” x 26.3” x 25.4”)
Gross Weight: 35.5 kg (78.2 lbs)
