Harman JBL Libra 150 - Rear Panel Controls and Connectors

Battery Terminal Block Connects to the total 24V (Libra 150) battery as
Fan
standby power source.
Cooling Vents
Grounding point  Provides grounding connections of the unit.
Speaker Terminal Block (4/8 )  Connects to the 4 or 8 speakers.  
Speaker Terminal Block (70V/100V)  Connects to speakers with 70V or 100V
transformers.
AUX Input  May connect a device with unbalanced RCA output, such as a tuner,
tape player or audio mixer.
Line input  Connects to a input device, such as a CD player or an external mixer
to enhance the number of input.
media recorder for recording purpose.
power output.
Rubber Foot
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
K.
L.
M.
N.
Mains wire (3 - Pole)
B G F D C
E H IA J K M L N
CLASS 2
WIRING
24V DC
+ -
CB
DC FUSE T7.5A
CAUTION
WARNING: SHOCK HAZARD -DO NOT OPEN
AVIS : RISQUE DE CHOC ELECTRIQUE -NE PAS OUVRIR
WARNING: TO REDUCE THE R ISK OF FIRE OR
ELECTRICAL SHPCK, DO NOT EXPOSE THIS EQUIPMENT
TORAIN OR MOISTURE.
AVI S: RISQUE DE CHOCELECTRIQUE -NE PAS OUVRIR.
AVERTI SSEMENT - ENERGIE ELECTRIQUE
DANGEREUSE' VOIR LE CAHIER D' INSTRUCTIONS.
OUTPUT
LINEPREAMP
AUX
INPUT
LIN E
L
R
220-240VAC ~ 50/60Hz
COM 4Ω 8Ω 0V 70V 100V
5
1.The output level will be controlled by booster amplifier.
Rear Panel Controls and Connectors
Rear View
LIBRA 150
7.5
