Harman JBL PARTYBOX 710 - AUX Connection; Microphone and Guitar Mixing

1010
6.4 AUX Connection
1. Connect an external audio device to the speaker through a
3.5 mm audio cable (not supplied).
2. After stopping playback from any other source, start audio
playback on the external device.
6.5 Mixing Sound with a Microphone and /
or Guitar
By using a microphone or electric guitar (not supplied), you can
mix sound with an audio source.
Notes:
– Always set the guitar or microphone volume to the minimum level
before guitar or microphone connection / disconnection.
– Always disconnect the guitar or microphone when you are not
using them.
6.5.1 Connecting a Microphone
1
2
1. Connect a microphone to the or socket.
2. When connecting a microphone to the socket, switch
the slider to show .
6.5.2 Connecting a Guitar
1
2
1. Connect a guitar to the socket.
2. Switch the slider to show .
