1414
10. TROUBLESHOOTING
Caution:
– Never try to repair the product by yourself. If you have any
problems while using this product, check the following points
before you request service.
System
The speaker will not turn on.
• Check the AC power connection.
No response from some buttons
• The product may be in demo mode. In demo mode, all the
input sources and buttons, except / / and the
volume and light pattern knobs, are disabled. Hold and
simultaneously for more than 5 seconds to exit.
Sound
No sound from the speaker.
• Ensure that the speaker is powered on.
• Adjust volume.
• Ensure that a sound source is active and not muted.
Bluetooth
A device cannot connect with the speaker.
• Ensure that the Bluetooth function of the device is enabled.
• The speaker is already connected with another Bluetooth
device. Hold
on the speaker for more than 20 seconds to
disconnect and pair with a new device.
Poor audio quality from a connected Bluetooth device
• The Bluetooth reception is poor. Move the device closer to
the speaker, or remove any obstacle between the device and
speaker.
9. SPECIFICATIONS
Transducers: 2 x 216 mm (8") woofer,
2 x 70 mm (2.75") tweeter
Output power: 800 W RMS (IEC60268)
Power input: 100 – 240 VAC ~50 / 60 Hz
Frequency response: 35 Hz – 20 kHz (-6 dB)
Signal-to-noise ratio: > 80 dB
Cable type: right-angle AC power cable (type
varies by regions)
Cable length: 2.0 m / 6.6 ft
USB charge out: 5 V / 2.1 A (max)
USB format: FAT16, FAT32
Bluetooth
®
version: 5.1
Bluetooth
®
prole: A2DP V1.3, AVRCP V1.6
Bluetooth
®
transmitter
frequency range: 2400 MHz – 2483.5 MHz
Bluetooth
®
transmitter
power: ≤ 11 dBm (EIRP)
Bluetooth
®
transmitter
modulation: GFSK, π/4 DQPSK, 8DPSK
Supported formats: .mp3, .wma, .wav
Aux-In: 250 mVrms (3.5 mm connector)
Mic-In: 20 mVrms
Guitar-In: 100 mVrms
Bluetooth/USB input: -12 dBFS
Product dimensions
(W x H x D):
399 mm x 905 mm x 436 mm /
15.7" x 35.6" x 17.2"
Net weight: 27.8 kg / 61.3 lbs
Packaging dimensions
(W x H x D):
1048 mm x 505 mm x 467 mm /
41.26" x 19.88" x 18.39"
Gross weight: 31 kg / 68.34 lbs
