01/11
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
3 Flue Tail Pipe 3-00-247237
4 Auger Motor Cover 2-00-773852P
5 Auger Motor Shield 2-00-773815P
6 Differential Switch 3-20-6866
7 Distribution Blower 3-21-22647
8 Combustion Blower 3-21-08639
9 Rear Cover Left 2-00-773828-1P
10 Rear Cover Right 2-00-773828-2P
11 Comb Intake Weldment 1-10-08516S
12 Retainer Assembly 1-10-08533S
13 Ash Pan 1-10-7738108A
14 Ash Door Assembly 1-10-7738106A
15 Bolt on Hinge 2-00-06952B
16 Cast Door Frame 4-00-06800P
17 Glass Panel 3-40-950133125
18
Door Handle Assembly
1-00-453001
Wooden Handle w/Hardware, Load Door 1-00-00247
19 Burn Pot Weldment 1-10-00675
Flame Guide 3-00-03000
Clean Out Cover 2 Sets 1-00-06623
Thumb Screw Pkg of 10 3-31-782108-10
20 Fire Brick 4-1/2 x 9 x 1-1/4” Pkg of 7 1-00-900450125
21 Hopper Heat Shield 2-00-773854B
22 Feeder Cover 2-00-773826L
23 Circuit Board 1-00-05886
Circuit Board Plate 1-10-08327
Knob, Contol Board/D-Shaft 25 Sets 1-00-015605
Additional service parts on following page.
To Next Page
