Harman P61 User Manual

Harman® • P-Series Owner’s Manual_R23 • 2014 - ___ • 02/1913 3-90-436168c
The P-Series Pellet Stove is more than just automatic ignition,
it is also automatic temperature control. The automatic
systemwillallowtheresizetobeadjustedtomatchthe
heatingneedsandevenputthereoutifnecessary.Ifheat
isneededafterthereisout,theP-SeriesPelletStovewill
automaticallyre-igniteandadjusttheresizetomatchthe
heating need. The totally automatic room sensor mode is
recommended because of its efciency.The unit can be
switched between "AUTO" and "DISABLED" at any time
during operation.
Igniter switch to “AUTO”
Room Temperature Mode
In “Room Temp Mode” heat output is controlled automatically
by the Room Sensing Probe. When the Room Sensing Probe
calls for heat, the stove will increase output. When the Room
Sensing Probe is getting close to the set temperature, the
stovewillbegintoleveloffoutputandkeepthereburning
at just the right temperature to maintain that setting.
High output is determined by the Feed Limit setting. This
setting, generally on #4, can be increased if higher burn rates
arenecessary(Figure4.6).Theunit’smaximumburnrate
should not create less than 1” of ash on the burn pot front
edge(Figure4.7).Overfeedingisnotasafetyconcern,but
fuel may be wasted if unburned pellets fall into the ash pan.
In “Room Temp Mode” a constant fuel consumption rate is
sacricedforexactroomtemperature.Therefore,asitgets
colder more pellets will be burned automatically.
The distribution blower speed will vary according to the
positionofthemodeselectorpointer,andresize.
Igniter switch to “AUTO”
Constant Burn Mode
This allows for automatic ignition upon start-up only. The unit
can then be set at any desired setting. The heat output and
fuel consumption will remain constant regardless of room
temperature. The unit’s maximum feed rate should not create
less than 1” of ash on the burn pot front edge. Figure 4.7.
The unit’s low burn or maintenance setting is as low as it will
go. It will not go out unless it runs out of fuel or is turned off.
Shut-Down Procedure
To kill the re or stop burning the stove, turn the Mode
Selectorto“OFF”.Thiswillcausetheretodiminish and
burnout.Whenthereburnsoutandthestovecoolsdown
everything will stop.
If you pull the plug to shut down the stove, all motors will stop.
This may cause incomplete combustion and smoke in the
rebox.Iftheloaddoorisopened,thesmokemayescape.
The best way to shut down the stove is simply let it run out
of pellets, then the stove will shut down automatically.
Room Temperature Mode: This setting will produce a room temperature
of 70 degrees with the distribution blower at medium speed.
This setting will produce medium heat with the distribution
blower on "low".
This setting will produce continuous maximum heat output with
the distribution blower at full speed.
Constant burn Mode
E. Automatic Ignition (Continued)

Harman P61 Specifications

General

Blower	Yes
Ash Pan	Yes
EPA Certified	Yes
Type	Pellet
Weight	320 lb
