P68 Pellet Stove
P68 Maintenance - Cleaning the Feed System
Pelletneswillaccumulateinthefeederbodyover
a period of time; therefore, a yearly inspection and
cleaning of this must be performed.
Tocleanoutnes:
1. Remove right rear cover panel.
2. Remove wing nut and feeder cover on the right
side of the feeder.
3.Useavacuumcleanertoremoveallnes.
4. Reinstall feed cover, wing nut, and right rear
cover panel.
Fig. 39
Pellet Fines may build up in this area
5/16" Hex Head
Screws (2 on
each side)
5/16" Hex Head
Screws (2 on
each side)
The low draft sensor switch monitors the air
pressure in the hopper. Depending on the amount
ofnesinthefuelbeingburned,thistting,known
asthemufer,mayneedtobecleanedperiodically.
Notethelocationofthemuferandusecaution
when cleaning or emptying the hopper.
