Starting A Fire Automatically
1. MIN. TEMP. Selector to “OFF”. Thisresetsthecontrol
inadditiontoturningitoff.
2. Clean Burnpot withscraper,ifnecessary.Thisisusually
aweeklymaintenanceprocedure.Cleaningtheburnpot
withthescraperwithasmallamountofnewfuelinthe
bottomisnotaproblem.First,scrapetheashesonthe
frontoftheburnpotintotheashpan.Thenscrapethe
holegridsurfacedownwardintotheburnpot.Whenthe
stoveisignitedthesescrapingswillbepushedoutbythe
feeder.
Theillustrationat leftshowsthehopper swingplateopen
foreasyaccesstotheburnpot.Theburnpotcanalsobe
reachedthroughthereboxdoor.
NOTE: To minimize the amount of stress placed on the
hopper swing plate hinges, opening of the hopper swing
plate should be done with the least amount of fuel in the
hopper as possible.
3. Fill Hopperwithpellets.Whenllingthehoppercheck
forexcessivenesinthebottomofthehopper.Fines
aresmallpiecesofbrokenpellets(sawdust).Finesdo
notoweasilyandoftenbuilduponthehopperfunnel
bottomangles.Thesenescanbepushedintothe
feederopeningandthenllthehopperwithpellets.As
thesystemworks,theywillbeburned.
4. If Starting After an Empty Hopper, Turn Feed Adjuster
to “TEST” (forone60secondcycle).Thiswillfeedpellets
intotheaugertubeandalsoallowyoutocheckthemotors
foroperation.NOTE: The auger motor will not operate
with any of the doors open.
5. Turn Feed Adjuster to #4. Ifthisisyourrstreoryou
aretryingdifferentpellets,setthefeedadjusterto#4,This
isanaveragenumberformostpelletsandmayneedto
beadjustedforyourparticularfuel.Afteryouknowafeed
ratesettingthatworkswellforyourapplication,usethat
setting.
NOTE: You know your feed rate is too high when: The
overheat safety feature is energized each time the
heating zone demand turns off during a high burn. OR,
If unburned or partially burned pellets are found in the
ash pan. (This may also be an indication of a burn pot
in need of scraping.)
6. Flip the Igniter Switch up intothe“AUTO”position.
7. Turn the MAX. TEMP. Dial onthecontrolboardtothe
desiredtemperature.Thissettingmustalwaysbeatleast
5°F.higherthantheMIN.TEMP.setting.
Automatic Ignition
Scrape burnpot to remove any carbon
build-up that may have occured
HOT WHILE IN OPERATION. KEEP CHILDREN,
CLOTHING, AND FURNITURE AWAY. CONTACT MAY
CAUSE SKIN BURNS.
WARNING
!
