Ash Removal
Disposal of Ashes
Ashesshouldbeplacedinasteelcontainerwithatighttting
lid.Theclosedcontainerofashesshouldbemovedoutdoors
immediatelyandplacedonanon-combustibleoororonthe
ground,wellawayfromallcombustiblematerials,pending
naldisposal.Ifashesare disposedofbyburialin soilor
otherwiselocallydispersed,theyshouldberetainedinthe
closed container until all cinders have thoroughly cooled.
Otherwasteshallnotbeplacedinthiscontainer.
Soot and Flyash: Formation and Need for Removal
The products of combustion will contain small particles
of yash. The yash will collect in the exhaust venting
systemandrestrict theowofthe uegases.Incomplete
combustion, such as occurs during startup, shutdown, or
incorrectoperationoftheroomheaterwillleadtosomesoot
formationwhichwillcollectintheexhaustventingsystem.The
exhaustventingsystemshouldbeinspectedatleasttwice
monthlytodetermineifcleaningisnecessary.Payparticular
attentiontoscreeningintheventcap.Thescreen,ifpresent,
willaccumulatewithashesratherquickly.
Fig. 21
Ash Door Handle
Ash Door
Ash Pan
Ash Pan Handle
Ash Removal
Itisrecommendedtoremovetheasheswhentheboilerisnot
inoperation.Thislessensthechancesofcomingincontact
withhotsurfaces.Ashescanberemovedwhileinoperation
but,extracaremustbetaken.
Open Ash Door
Liftthelatchandopenthedoorasshowning.21.
NOTE: Keep hopper lid, hopper swing plate, rebox door
and ash pan door closed during operation and maintain
all seals in good condition.
Remove Ash Pan
Alwayswearglovestoremoveashpan.Grabtheashpan
bythengerholdandpullitoutoftheboiler.Lifttheashpan
bythengerholdanduseitforcarryingtheashpan.Close
the ash door before disposing the ashes.
WARNING
!
RISK OF FIRE!
• Ash, soot or creosote build-up may cause
overheating or re.
• Routine cleaning of heat exchangers and venting
is required.
