Filter Box Assembly, Cont’d
3. Placethelterframepanelinsidethebottomandinside
thesolidpanelcorner.SeeFigure5.4forcornerdetail.
MakesurethatthelteropeningisupFigure5.3Holdthe
lterpaneltothesolidpanelwithaTekscrewinthemiddle
holeofthesolidpanel,andoneinthebottommiddlehole
underthelteropening.
NOTE: Do not put any screws into any of the top holes
at this time.
FilterFramePanel
Filteropeningmustbeup
4. Placetheremainingpanel,(inthiscasethebloweraccess
panel)inthebottompanelandintothecornerofthesolid
panelFigure5.5.Makesurethatthepanelisintheupright
position.Therearenocovermountingholesinthebottom
edgeofthispanel.HoldthepanelintoplacewithoneTek
screwinthemiddleholeofthesolidpanelandoneinthe
bottommiddleholeofthebloweraccesspanel.
Figure 5.3
Figure 5.4
Figure 5.5
