Harman PF-120 Installation Manual

Harman® • PF-120 Installation Manual_R1 • 2014 -___ • 03/1417
3-90-08121i
ThisEdgeToward
Furnace
Bottom
SolidSidePanel
Knockouts
Tekscrewfromoutside
A. Return Air Box Assembly
Thecoldairreturnlterboxcanbeassembledwiththelter
frameoneithersideortheback,providedthereisaccessto
thecombustionbloweranduearea.
1. Placethebottom on the oor.The edge closest to the
knockouts will be the edge towards the furnace. See
Figure5.1.
2. Placethedesiredverticalpanelinsidethebottomtrayand
holdintoplacewithoneTekscrewinthebottommiddle
hole.(solidpanelshown)SeeFigure5.1.
Figure 5.1
5
Appliance Set-Up
Figure 5.2
Bottom(sameastop)
Top(sameasbottom)
FilterFrame
SolidSidePanel
BloweraccessPanel
Bloweraccess
PanelCover
Filter
