Ui12, Ui16 User Manual
5.0: CHANNEL EDIT
CHANNEL EDIT
5.0: CHANNEL EDIT
The EDIT page is the basic access point for channel-based signal processing: EQ, dynamics, and FX
and auxiliary sends. The actual processing and options available depend on the channel type.
The selected channel strip will be shown on the left of the EDIT screen. In the phone software, the
default EDIT page is a via-point for more detailed views and also offers access to basic channel
parameters such as pan/balance, phase, phantom power, and more.
EDIT PAGE ACCESS
The EDIT page is available from a number of different Ui Software screens. To select the EDIT page directly
either click/tap the EDIT button in the top-line navigation bar (tablet software) or select the EDIT menu item
(phone software).
Alternatively you can:
• Double click/tap on a channel fader cap to navigate to channel EDIT mode EQ tab.
• Double click/tap on channel label (channel types: INPUT, LINE IN, PLAYER, SUB GROUP, AUX) to navigate to
selected channel EDIT page DYN tab.
• Double click/tap on a channel label (channel type: FX RETURN) to navigate to selected channel EDIT page FX
tab (Global FX parameters).
