5.2 Operations Overview > Vistonics II
Buttons On/Off
If a function is assigned to a button it is displayed as shown. The 'active' state shows
the button highlighted in a lighter colour.
Open Touch
Page
If the button can open a conguration page in the Touch area it shows a '+' sign on
the button. If the conguration page is already open, the button will be labelled with a
'-' sign. Pressing the button in that state will exit the conguration page.
Inactive Fields
If an audio function block is disabled, with the background of the eld changed to
grey, the button indication will change to a darker colour.
