Vi3000 USER MANUAL
5.4 Operations Overview > FaderGlow™
5.4: FaderGlow™
Soundcraft FaderGlow™ (Pat. Pend.) is a unique feature that gives the user an additional level of status indication,
and can signicantly reduce operating errors.
On the console, several different functions can be assigned to a particular fader, it can therefore be easy to forget
which function is currently being controlled, especially when grabbing a fader in a hurry. The main principle of Fader-
Glow is therefore to indicate the actual function type that is currently assigned to a particular fader. Soundcraft Fader-
Glow is tted to all 32 Faders that can change their function.
FADER OPERATION Soundcraft FaderGlow™ COLOUR
Channel level NONE
AUX send level ORANGE
GRP (fader closed) GREEN
MTX contribution level CYAN
VCA Master 1..8 BLUE
VCA Master 9..16 PINK
Aux VCA Master 1..16 WHITE
