HELIX: Owner's Manual
24SEP2021 | 610-00039-01 REV D
6
INTRODUCTION
HELIX CURVED STAIRLIFT: SECTION 2
KEY STAIRLIFT FEATURES
The Helix stairlift can be folded at its parking position to save space.
The distance between rail and wall is much smaller, compared to other stairlifts. And, the maximum angle of
inclination is higher than any other stairlift system. The high quality construction allows the use over most
barriers and can be used in a home or a business with two, or more floors.
1. Retractable seat belt
2. Emergency stop (optional)
3. Footrest with obstruction sensors
4. Seat swivel release bars
5. Obstruction sensors for the rail and step
6. Folding armrests
7. Folding seat
8. Key lock (optional)
9. Power switch
10. Status light
Red: Major fault
Yellow: Obstruction
Green: Ready
11. Power light
12. Charging light
13. Diagnostic port
1
2
3
4
5
6
7
8
9
10
11
13
12
