SL300 PINNACLE STAIRLIFT: Owner’s Manual
22MAR2024 | 610-00058 G
6
INTRODUCTION
PINNACLE STAIRLIFT: SECTION 2
KEY STAIRLIFT FEATURES
1. Armrests
2. Up/Down hand control
3. Seatbelt
4. Chassis obstruction sensors (optional)
5. Seat swivel release bars
(not used on power swivel)
6. Footrest with obstruction sensors
7. Power footrest switch (optional)
SAFETY FEATURES
• There are sensors on the top and bottom ends of the chassis (on units equipped with optional Folding Rail
only), and on the footrest. If any of these edges touches an obstruction the lift will halt immediately.
• Seat swivel interlocks prevent the lift from being operated unless the seat is in its locked, forward facing,
travel position.
• Remote controls are disabled for 15-seconds after the armrest control is used.
• A seat belt is provided and must be secured around the user to prevent an inadvertent fall.
1
2
3
4
7
5
6
