Care and Maintenance
ANNUAL MAINTENANCE
The rail gear should be cleaned once a year or more frequent if exposed to contaminants such as pet hair,
excessive dust, etc. Wipe or vacuum debris from the gear teeth. Apply a small amount of lubricant onto a
clean cloth and wipe across the gear teeth. Do not apply too much lubricant, over lubricating will attract dirt
and debris.
Ensure all rail and seat support fasteners are tight.
SHOCK
WARNING
To prevent electrical shock or damge to the lift, disconnect the 120 VAC power when cleaning the
lift. Never apply cleaning liquids directly on the rail mounted charging stations or electrical safety
switches.
MANUAL LOWERING TOOL
TIP
The lift and aluminum rail can be cleaned with any commercial window cleaner.
DO NOT USE abrasive cleaners.
If the lift is inoperable because it has driven onto the nal limit switch, it has to be manually moved o
the nal limit.
TIP
Gear rack should be lubricated with a multi-purpose calcium grease.
DO NOT USE any type of light weight penetrating oil (WD-40, GUNK, Kroil,
Liquid Wrench etc.)
1. Turn the lift o at the power switch.
NOTE: Disconnecting the power supply does not
turn the lift o. The power supply only charges the
batteries.
2. Remove the round plastic plug on the side of the
chassis to access the end of the motor shaft.
[Figure 5-1]
3. Place the manual lowering tool onto the end of
the motor shaft and rotate until the nal limit switch
becomes disengaged.
4. Re-install the plastic plug and turn the lift "ON".
[Figure 5-1]
