The cup holder is stored in the cavity on
the underside of the booster seat base.
• To remove from storage, pull the cup
holder.
TO INSTALL:
1. Slide cup holder into place over cup
holder clip ❶❷ on either side unl
locked in place.
TO REMOVE:
1. Pull cup holder up and outward.
USING SHOULDER BELT GUIDE
1. Slide the vehicle’s shoulder belt into
the RED shoulder belt guide ensuring
it is at. Posion the belt guide just
above the child’s shoulder ❶.
! THE VEHICLE’S SHOULDER BELT
MUST LIE ACROSS THE CHILD’S
SHOULDER.
! All straps MUST be ght and
NOT twisted. ALL slack MUST be
removed from lap and shoulder
porons of the 3-point vehicle belt
to ensure a snug t.
❶
This booster seat is NOT CERTIFIED for aircra use. Aircra
seats are not equipped with 3-point lap-and-shoulder
belts which are required for use with this booster seat.
AIRCRAFT INSTALLATION
23
