260-668066-001 Rev 024 February 2009 Vol. II-1-15
Eclipse User Manual
• 4x to 106x E1 or 4x to 127xDS1
• 1x to 4x E3 or 1x to 4xDS3
• 1/2x STM1/OC3
• Up to 300 Mbps Ethernet
• QPSK to 256QAM modulation
• RAC 30, RAC 40, RAC 3X, RAC 4X, IDU 300 series
ODU 300ep supports:
• 5, 13 or 15 GHz
• Extended high power transceiver
• 4x to 106x E1 or 4x to 127x DS1
• 1x to 4x E3 or 1x to 4x DS3
• 1/2x STM1/OC3
• Up to 300 Mbps Ethernet
• QPSK to 256QAM modulation
• RAC 30, RAC 40, RAC 3X, RAC 4X, IDU 300 series except IDUsp
Table 1-2. ODU Characteristics for Eclipse INU/INUe Operation
Item
1
ODU 300ep ODU 300hp ODU 300sp
Frequency
Bands
5 to 23 GHz 6 to 38 GHz 7 to 38 GHz
Capacity 5 to106xE1, 1 to 4xE3
4 to 127xDS1, 1 to4xDS3
2xSTM1/OC3
10 to 360 Mbps Ethernet
5 to 106xE1, 1 to 4xE3
4 to 127xDS1, 1 to4xDS3
2xSTM1/OC3
10 to 360 Mbps Ethernet
4 to 40xE1 (ETSI only)
10 to 80 Mbps Ethernet
Modulation
Options
QPSK, 16QAM, 32QAM,
64QAM, 128QAM,
256QAM
QPSK, 16QAM, 32QAM,
64QAM, 128QAM,
256QAM
QPSK or 16QAM
2
Bandwidths
Supported
3.5 to 56 MHz ETSI
2.5 to 80 MHz ANSI
7 to 56 MHz ETSI
2.5 to 80 MHz ANSI
7 to 28 MHz
Tx Power Extended power (except
11 GHz.
30 dB (QPSK) to 22 dB
(256 QAM) power control
range
High power
20 dB (QPSK) to 14 dB
(256 QAM) power control
range
Standard power
20 dB (QPSK) or 18 dB
(16 QAM) power control
range
Max Tuning
Range
Typically (depending on T/R spacing) 56 MHz at 6 / 7 GHz to 230 MHz at 15
GHz. 340 to 380 MHz on higher bands.
IF Interface RAC 30, RAC 3X, RAC 40,
RAC 4X, IDU 300 series
except IDU 300sp
RAC 30, RAC 3X, RAC 40,
RAC 4X, IDU 300 series
RAC 30, IDU 300 series
except IDU 155o
