Table 1-7.
IDU GE 20x Compatibility with INUs and IDUs: ANSI
200 40 128 QAM N/A X N/A N/A
200 56 64 QAM N/A X X N/A
Ethernet BW
Mbit/s
BW
MHz
Modulation RAC 30v3
& RAC30A
RAC3X IDU ES IDU
20xV21
25 5 128 QAM X N/A N/A X
25 10 16 QAM X N/A N/A X
25 20 QPSK X N/A N/A X
50 20 16 QAM X N/A X N/A
50 40 QPSK N/A X X N/A
100 20 128 QAM N/A N/A X N/A
100 20 64 QAM N/A N/A X N/A
100 30 32 QAM X N/A X N/A
100 40 16 QAM N/A X X N/A
130 30 64 QAM X N/A N/A N/A
150 30 128 QAM N/A X X N/A
150 40 32 QAM N/A X X N/A
150 50 16 QAM X N/A X N/A
200 40 128 QAM N/A N/A X N/A
200 50 64 QAM N/A N/A X N/A
Ethernet BW
Mbit/s
BW
MHz
Modulation RAC 30v3
RAC30A
& RAC 30v2+
RAC3X IDU ES IDU
20xV22
