475 Field Communicator Overview
5
Figure 1. 475 Field Communicator
HART and FOUNDATION
fieldbus Communication
Terminals (top)
Stylus (in the
strap)
Bluetooth
®
Light
IrDA
®
Interface (top)
Touch Screen
Display
Strap attachment
(top)
Backlight Key
Strap
Attachment
(side)
Enter Key
Function Key
and Light
(for multiple-key
combination
functionality)
Li-Ion Battery
(back) and
System Card
(internal)
Strap Attachment (side)Strap Attachment (side)
Lights
Illuminated by
Pressing the
Charge Indicator
Button (side)
Alphanumeric
Keypad
Tab Key
Navigation Keys
(four arrow keys)
Strap
Attachment
(side)
Power Key and
Light
Charge
Indicator
Button (side)
Green Power
Supply/Charger
Connector on
the Battery
(side)
