Harvest TEC 201LS - Introduction and Setup; Requirements; Tools Needed

3
H
2
O Moisture Owner’s Manual Table of Contents
Page
Introduction
3
Installation of Star Wheels
4-7
AGCO Balers – Non-UHD Models
4
AGCO Balers – UHD Models
4
Claas Balers
5
CNH BB & LB Balers
5
John Deere L330-L341 Balers
6
Balers Not Listed
7
Alternative Star Wheel Mounting Location
7
Control Box Installation
8
End of Bale Sensor Installation - 200FCA (Optional)
8
Dye Marker Installation - 200DM (Optional)
9
Wiring Diagram
10
Downloading H
2
O App
11
Screen Definitions
11
Operation
12-13
Reading Moisture
12
Moisture Range
12
Dye Marker System
13
Dye Sprayer Override
13
H
2
O Firmware Update through App
14
Pin Outs
15
Parts Breakdown
16-18
Star Wheels
16
Control Box & Harnesses
17
Fixed Chamber End of Bale Sensor Kit
17
H
2
O Dye Marker
18
Warranty Statement
19
Introduction
Congratulations and thank you for purchasing a Harvest Tec H
2
O Moisture Sensing Kit Model 201LS system.
Please read this manual carefully to ensure correct steps are taken to attach the system to the baler. This
system is designed to read moisture at levels of 5-60%.
Requirements
The app will support operation of the current operating system and one previous version for both Apple and
Android devices.
**It is recommended for proper communication that the original phone/tablet power cable is used. Many lower cost power
cables do not meet requirements to properly charge and communicate to the Harvest Tec H2O module.
Tools Needed
SAE wrench set
Hammer
Drill bit set
Standard screw driver
Measuring tape
Center punch
Side cutter
SAE socket set
