The Kyoto stove, certifi ed in compliance with DIN-EN 13240 : 2001 + A2 2003 and Art.
15 a B-VG (Austria), can only be operated when the fi re box is closed; more than one
device can be connected to the chimney, if the reduction panel was installed.
VKF No.: 11670; Inspection Report No. (A): FSPS-Wa 1775-A
The following data applies to the chimney characteristics in accordance with EN 13384-1 / -2:
Combustion Values Wood
Nominal Thermal Output 9 kW
Waste Gas Mass Flow Rate 10 g/s
Waste Gas Outlet Temp. 270 ˚C
Min. Supply Pressure at Nominal Thermal Output 11 Pa
CO content at 13% O2 1488 mg/m³
Effi ciency 78 %
Particulate 35 mg/m³
Depending on the insulation of the building, the nominal thermal output of 9 kW
indicated on the unit‘s type plate is suffi cient for 35 - 130 m² (subject to change).
Dimensions:
Height Width Depth
Stove 146,5/152 cm 57 cm 52,5 cm
Fire Box 62 cm 28 cm 30 cm
Weight 207 kg
Connection Dimensions:
Connection height 143,5 cm
Connection height back, pipe centre 133,5 cm
Distance from back wall of stove to fl ue pipe centre 14,5 cm
Connection height Combustion air inlet, pipe centre* 13 cm
Fire Box Opening 500 cm²
Flue Pipe Diameter 150 mm
Flue Pipe Diameter Hase-Combustion air inlet* 100 mm
Connection branch top (rear installation possible.)
*For separate air supply in low-energy houses and insuffi cient combustion air supply in the
room where the stove is installed
