92
Connecting Piece, exterior
Pipe Bend 90°, Ø 100 mm
Connecting Piece, interior
Rosette
Combustion Air Connection, customer-
provided:
- Min. Ø 100 mm
- max. Length 5 m, with max. 2 bends
e.g. Drain Pipe (PVC pipe) Ø 100
Straight pipe
fi g. 13: Connection to an Air Supply Pipe Typ FC
