91
Seal the three-piece flue pipe set
with the Hase special sealing paste
Wall Sleeve
Seal connection at chimney with
sealing cord or heat-resistant silicone
Seal at flue pipe exit piece
with Hase Special Sealing
Paste
Connecting Piece, interior
Rosette
Stainless Steel Pipe,
Connecting Piece, interior
Air/Flue Gas System (AFS):
AFS Flue Gas Chimney
AFS Air Supply
28. Socket variations Tula direct vent stove
fi g. 12: Connection to an Air/Flue Gas System (AFS) Typ FC
41x
