HATO 200C - Adjusting Obstruction Force Sensitivity

13
7. The door will now do a complete open & close cycle.
DOWN
UP
SET
CODE
CODE
SET
UP
DOWN
DOWN
UP
SET
CODE
1 2
3
4
CODE
SET
UP
DOWN
DOWN
UP
SET
CODE
5
6
DOWN
UP
SET
CODE
UP
SET
CODE
DOWN
7
The door will do a complete open
&close cycle.
Fig.16
Adjusting obstruction force sensitivity
If the door meet an obstruction during closing, it will stop and reverse about 15cm~20cm.
1. Press and hold SET four seconds until ‘P1’ is indicated on the LED display.
2. Press UP button, ‘P2’ is indicated on the LED display.
3. Press the SET, the unit is now in force adjustment mode. Note: the factory preset is F5.
4. Press UP to increase force setting, maximum force setting is level 9 (F9). Press DOWN to
decrease force, minimum force setting is level 1(F1).
5. Press SET to confirm.
