Maintenance 2G40, 2G40 H
70
HATZ
Operator’s Manual
2 Wing nut
3 Cover
4 Dust discharge valve
5 Collar nut
6 Filter cartridge
7 Sealing lip
8 Guide apparatus
9 Filter housing
Procedure – Removing the air filter cartridge
Step Activity
1 Take off and clean the rain cap (1).
2 Undo the wing nut (2) and remove the lid (3) with dust discharge
valve (4).
3 Check the lid and dust discharge valve for deformation, aging
and tears; replace if necessary.
4 Unscrew the collar nut (5).
5 Carefully pull out the filter cartridge (6).
6 Damage in the filter area (6) and in the area of the sealing lip (7)
preclude further use.
7 Pull the guide apparatus (8) out of the filter housing (9).
8 Clean all parts – excluding the filter cartridge. Ingress of dirt or
other foreign bodies into the intake opening of the engine must
be strictly avoided.
Procedure – Checking and cleaning the air filter cartridge
NOTICE
i
▪ The pressure must not exceed 5bar.
▪ The filter cartridge may not be washed out or beaten out.
▪ Even minor damage in the areas of the sealing lip, filter pa-
per or filter cartridge makes it impossible to reuse the filter
cartridge.
