PARTS LIST & ASSEMBLY
DIAGRAM
Part Description Qty.
1 Cab Bar 1
2 Front Side Frames 2
3 Back Side Frames 2
4 Front Left Leg Stand 1
5 Front Right Leg Stand 1
6 Rear Left Leg Stand (with welded tip) 1
7 Rear Right Leg Stand 1
8L, 8R Front Mounting Feet 2
9L, 9R Rear Mounting Feet 2
10 Front Bar 1
11 Center Bar 1
12 Rear Bar 1
13 Clamps 4
14 Coupler Riser 4
Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts.
Please note: Hardware
not shown
1
2
2
3
3
4
5
6
7
8R
8L
9L
9R
10
11
12
13
13
14
14
14
14
