Maintenance book
C 8 (C 2032E) - C 8W (C 2047E) - C 10 (C 2747E) - C 10N (C 2632E) - C 10N-1 - C 12 (C 3347E) -
C 14 (C 3947E) - C 10RTE (C 2668RTE) - C 12RTE (C 3368RTE)
2420333720 E07.16 USA / GB
Maintenance book
ELECTRIC SCISSOR LIFTS
C 8 (C 2032E) - C 8W (C 2047E) -
C 10 (C 2747E) - C 10N (C 2632E) - C 10N-1 -
C 12 (C 3347E) - C 14 (C 3947E) -
C 10RTE (C 2668RTE) - C 12RTE (C 3368RTE)
USA

Table of Contents

Questions and Answers

  • W
    whitney51Aug 16, 2025
    What to do if Haulotte Group C 2632E platform does not lift?
    • J
      jeffrey60Aug 16, 2025
      If the platform of your Haulotte Group Lifting System isn't lifting, consider these possible causes and solutions: * The load in the platform might be too heavy. Try reducing the load. * The hydraulic oil level could be low. Top up the oil level. * The tilt or slope may exceed the authorized limit. Avoid exceeding the authorized limit. * Outrigger cylinders may be incorrectly positioned. Ensure the machine is correctly stabilized. * Batteries may be more than 80% empty. Recharge the battery or batteries.
  • R
    Robert PhillipsAug 19, 2025
    Why is my Haulotte Group Lifting Systems hydraulic pump making an abnormal noise?
    • K
      kjohnsonAug 19, 2025
      An abnormal noise from the hydraulic pump in your Haulotte Group Lifting System could be due to insufficient hydraulic oil. Top up the oil level to resolve this.
  • J
    James AllenAug 22, 2025
    What to do if Haulotte Group C 2632E Lifting Systems hydraulic circuit is overheating?
    • M
      Mario SmithAug 22, 2025
      If the hydraulic circuit in your Haulotte Group Lifting System is overheating, it could be due to: * Oil viscosity level being too high: Drain the circuit and fill it with the recommended oil. * Insufficient hydraulic oil: Top up the oil level.
  • B
    Brandon MooreAug 25, 2025
    Why is my Haulotte Group Lifting Systems platform lifting and lowering jerky?
    • D
      Dennis ClarkAug 26, 2025
      Jerky lifting and lowering in your Haulotte Group Lifting Systems platform may be due to not enough hydraulic oil. In this case, top up the oil level.
  • M
    matthew78Aug 28, 2025
    What to do if Haulotte Group C 2632E has no movement with the lifting selector and joystick activated?
    • C
      Connie LeonardAug 28, 2025
      If your Haulotte Group Lifting System has no movement when the lifting selector and joystick are activated, consider the following: * A faulty selector: Check the movements with the lifting selector key set to the ground control box. * A faulty joystick: Replace the joystick. * Not enough hydraulic oil: Top up the oil level.
  • K
    Kristin DouglasAug 30, 2025
    What to do if Haulotte Group C 2632E has no movement with the selector in driving position and platform control box joystick activated?
    • M
      Michael HerreraAug 30, 2025
      If your Haulotte Group Lifting System isn't moving with the selector in the driving position and the platform control box joystick activated, check these possible causes: * Faulty joystick: Replace the joystick. * Not enough hydraulic oil: Top up the oil level. * Tilt or slope exceeding the authorized limit: Do not exceed the authorized limit. * The load in the platform is too heavy: Reduce the load.
  • D
    David ParsonsSep 2, 2025
    What to do if Haulotte Group C 2632E platform will not lower?
    • M
      Mary DavisSep 2, 2025
      If the platform on your Haulotte Group Lifting System won't lower, it might be because the load in the platform is too heavy. Try reducing the load.
  • J
    Joseph LewisSep 4, 2025
    Why does Haulotte Group C 2632E Lifting Systems machine race when lowering?
    • J
      Joshua WoodSep 5, 2025
      If your Haulotte Group Lifting System races when lowering, the balancing valve may be poorly adjusted or faulty. Adjust or replace the balancing valve.
  • T
    Taylor WilliamsSep 7, 2025
    How to fix Haulotte Group C 2632E steering system that works irregularly?
    • R
      Richard FarmerSep 7, 2025
      If the steering system on your Haulotte Group Lifting System works irregularly, the hydraulic oil temperature might be too low. Perform movements without any load to heat up the oil.
  • J
    Joel ThomasSep 10, 2025
    What causes hydraulic pump cavitation in Haulotte Group C 2632E Lifting Systems?
    • J
      Jacob WilliamsSep 10, 2025
      Hydraulic pump cavitation in your Haulotte Group Lifting System could be due to the oil viscosity level being too high. Drain the circuit and replace it with the recommended type of oil.

Summary

Safety Precautions

Safety Recommendations, Symbols, and Decals

Covers maintenance book importance, symbols used, and decal color codes for safe operation.

Manufacturers Warranty Details and Conditions

Outlines warranty acceptance, period, conditions, and exclusions for product coverage.

Scope and Instructions for Intervention

Defines intervention scope and provides instructions for safe and proper maintenance.

Recommendations for Use and Maintenance

Lubrication Diagrams and Ingredient List

Provides lubrication diagrams for different models and a list of ingredients with HAULOTTE® codes.

Consumables and Hydraulic Oil Specifications

Details consumables like filter cartridges and specifies hydraulic oil grades and properties.

Decals and Markings Locations

Illustrates the placement of decals and markings on various machine models.

Inspection and Maintenance Schedule

Maintenance Schedule by Periodicity

Details maintenance tasks based on time or operating hours for different machine components.

Inspection Program Overview

Outlines required inspections (periodic, reinforced, major) and responsibilities.

Daily Inspection Procedures and Forms

Describes the daily inspection process, including visual and functional checks and forms.

Periodic and Reinforced Inspection Details

Provides detailed programs for periodic and reinforced inspections, including daily checks.

Major Inspection Guidelines

Details major inspection procedures to ensure machine suitability and functionality after 10 years.

Diagnosis Assistance and Troubleshooting

Troubleshooting Common Malfunctions

Lists common problems, their probable causes, and recommended solutions for diagnosis.

Electric Circuit Diagrams and Components

Wiring Diagram - Main Components Nomenclature

Lists main electrical components and their markings for Compact 8-14 series.

Electric Circuit - Switches Description

Describes the function of various switches used in the electric circuit for different models.

Hydraulic Circuit Diagrams and Components

Hydraulic Circuit - Main Components

Lists main hydraulic components for Compact 8-12 and 10RTE-12RTE series.

Hydraulic Circuit - Solenoid Valves Details

Details solenoid valves for MK5 and MK6 hydraulic units with component markings.

Intervention Register

Record of Maintenance and Repair Work

Provides a template to record intervention details, including date, type, hours, and technician.
