Haulotte Group HA15IP User Manual (English)

Other manuals for Haulotte Group HA15IP

Questions and Answers:

J
John GarciaAug 19, 2025
Why is my Haulotte Group Boom Lifts not driving?
- S
  Sarah TurnerAug 19, 2025
  There are several reasons why your Haulotte Group Boom Lifts might not be driving. It could be due to the ground control box selector key being set to the ground control box position; in this case, turn the key to the platform control box position. Another reason might be the platform overload indicator; remove some weight to not exceed the authorised limit. Also, check that the 'Enable Switch' control validation device is enabled and pressed down during movement. Other potential causes include a faulty joystick (replace it), a damaged control box power cable (repair or replace it), exceeding the authorised tilt or slope limit (lower the arm and boom), being outside the temperature range (lower the arm and boom), or a faulty speed variator (check the diagnosis LED).
E
eclarkAug 25, 2025
Why is there no power in horizontal drive mode for my Haulotte Group Boom Lifts?
- M
  mathispaulAug 25, 2025
  If you're experiencing no power in horizontal drive mode on your Haulotte Group Boom Lifts, it might be because the reducing gear is not released (check the release solenoid valve) or the speed selector switch is in the wrong position (select the high speed (GV) mode).
R
Robin WatsonAug 26, 2025
How to troubleshoot no steering on Haulotte Group Boom Lifts?
- M
  Ms. Sonya SchaeferAug 27, 2025
  If you're experiencing a no steering issue with your Haulotte Group Boom Lifts, start by checking the hydraulic oil level and top it up if necessary. Also, ensure that the 'Enable Switch' control validation device is enabled and pressed down during movement. Verify that the driving movement is selected (choose low speed PV or high speed GV). Other potential causes include a faulty steering cylinder (repair or replace it), a damaged control box power cable (repair or replace it), or a faulty calculator drive (check the calculator connection).
J
Jacob MaysAug 28, 2025
What causes a Haulotte Group Boom Lifts pump not to work?
- B
  Benjamin LawsonAug 28, 2025
  Several factors can cause the pump in your Haulotte Group Boom Lifts not to work. These include a faulty speed variator (check the diagnosis LED), the main contactor/battery isolation switch being activated (pull the battery power switch- push button), a faulty start contactor (repair or replace it), faulty fuse(s) (replace the fuse(s)), discharged or faulty batteries (recharge or replace the batteries), poor contact on the battery cables (clean and tighten the terminals), or the 'Enable Switch' control validation device not being enabled (enable the device and keep pressed down during movement).
L
Louis ReyesAug 30, 2025
Why is my Haulotte Group Boom Lifts not reaching high speed?
- P
  Phillip MillerAug 30, 2025
  If your Haulotte Group Boom Lifts is not reaching high speed, it could be due to several reasons: the platform being extended (retract the arm, boom, and pendular arm below the horizontal axis), a faulty speed variator (check the connections), the speed selector switch being in the wrong position (select the high speed (GV) mode), or faulty batteries (replace the batteries).
A
acoleSep 1, 2025
What causes low hydraulic pump pressure in Haulotte Group Boom Lifts?
- C
  Cole NealSep 1, 2025
  Low hydraulic pump pressure or power in your Haulotte Group Boom Lifts can be caused by a faulty hydraulic pump (repair or replace the pump), the pressure regulation screw on the hydraulic unit not being properly adjusted (tightening by 3/4 turn increases pressure by 100 bar), a faulty valve body (replace the valve body), or a clogged oil filter (replace the oil filter cartridge).
J
Joseph PerkinsSep 3, 2025
How to fix a Haulotte Group Boom Lifts arm or boom that won't go up?
- T
  tony51Sep 3, 2025
  If the arm or boom on your Haulotte Group Boom Lifts won't go up, the batteries may be more than 80% empty; recharge the battery or batteries. It could also be due to a faulty load calculator; in this case, repair or replace the calculator.
D
David ShepherdSep 5, 2025
Why is my Haulotte Group Boom Lifts hydraulic pump making abnormal noises?
- M
  Michael MiddletonSep 5, 2025
  An abnormal noise from the hydraulic pump in your Haulotte Group Boom Lifts can be due to not enough hydraulic oil (top up the oil level) or broken or loose hoses/connectors on the inlet side (repair, tighten or replace the hoses or connectors).
J
Jennifer MontgomerySep 8, 2025
What could cause no low speed on Haulotte Group Boom Lifts?
- R
  Robert GentrySep 8, 2025
  If you're experiencing a lack of low speed on your Haulotte Group Boom Lifts, it could be due to a faulty speed variator (check the connections), the speed selector switch being in the wrong position (select the high speed (PV) mode), or faulty batteries (replace the batteries).
C
Christopher BoyerSep 10, 2025
How to troubleshoot a non-working load calculator on Haulotte Group Boom Lifts?
- D
  Debra BassSep 10, 2025
  If the load calculator on your Haulotte Group Boom Lifts isn't working, check for faulty fuses and replace them if necessary. Also, inspect for incorrect or loose electrical bundles and check or tighten the connections. If these steps don't resolve the issue, the load calculator itself may be faulty and require repair or replacement.

Haulotte Group HA15IP Specifications

General

Platform Capacity	230 kg
Weight	6550 kg
Max Slope	3°
Lift Capacity	230 kg
Drive Speed	5 km/h
Platform Width	0.8 m
Working Height	15 m

Summary

Safety Precautions and Recommendations

Operator Manual Recommendations

Guidelines for safe and efficient use of the HAULOTTE® product as per the operator manual.

Operator Manual Symbols

Explanation of symbols used in the operator manual to highlight safety precautions or practical information.

Safety Label Color Codes

Explanation of color codes for safety labels indicating danger levels and information.

Pre-Operation Safety Checks

Essential checks and instructions to perform before operating the machine to ensure safety.

Safe Operation Procedures

Guidelines and prohibitions for safe operation of the machine, including potential risks.

Intervenor's Responsibility

Owner's Responsibilities

Obligations of the owner or hirer regarding machine use, manuals, and local regulations.

Employer's Responsibilities

Employer's duty to issue driving permits and ensure operators are medically authorized.

Operator's Duties and Responsibilities

Operator's obligation to understand manuals, labels, operate safely, and report issues.

Machine Inspection and Maintenance Schedule

Table detailing responsibilities and frequency for pre-delivery, pre-operation, and periodical maintenance.

Machine Layout and Components

Machine Identification Plate

Information on the manufacturer's identification plate for specifying machine details.

Key Machine Components Diagram

Diagram illustrating the location of major components of the HA12IP - HA33JE machine.

Machine Safety Devices

Description of safety devices like the turntable rotation pin and intermediate guardrail.

Machine Safety and Information Labels

Classification and description of various labels (red, orange, yellow, etc.) indicating safety and technical information.

Operating Principle

Machine Operating Principle Description

Explanation of how hydraulic energy powers machine movements via an electric motor and pump.

Operating Principle Safety Devices

Details on safety devices like the 'Enable Switch' system for control activation.

Machine Drive Speed Control

Explanation of how the electronic variable speed unit controls movement and driving speed.

Driving Operations

Driving Recommendations

Managerial responsibilities and pre-use checks for safe driving operations.

Pre-Drive Machine Checks

Daily visual inspection and functional test procedures before operating the machine.

Functional Test Procedures

Steps for testing safety features, ground box, and platform box controls.

Special Procedures

Emergency Platform Lowering Procedure

Procedure for safely lowering the platform in case of operator incapacitation or control failure.

Manual Lowering for Repairs

Procedure for lowering the platform using a hand pump in case of main power failure.

Machine Towing Procedures

Instructions for disengaging and re-engaging drive hubs for towing the machine.

Machine Loading and Unloading

Guidelines and safety precautions for loading and unloading the machine, including transport position.

Technical Specifications

Machine Main Characteristics Overview

General information on machine characteristics, options, and compliance with directives.

Machine Overall Dimensions

Diagrams and specifications for overall dimensions of HA12IP/HA33JE and HA15IP/HA43JE models.

Machine Working Area Diagrams

Graphical representation of the working area and range of motion for HA12IP/HA33JE and HA15IP/HA43JE.

AS & CE Standard Compliance Tests

Details on overload, functional, and stability tests required for AS and CE compliance.

EC Declaration of Conformity

Formal declaration of compliance with EC directives for electric platforms.

Intervention Register

Maintenance and Repair Logbook

Record of maintenance and repair operations to benefit from the HAULOTTE® guarantee.
