Haulotte Group HA18PX - User Manual

143 pages

Save Page as PDF

To Next Page

Operator's manual

NGINE

POWERED

ARTICULATED

LIFTS

, 12 - 26

24203 3237 0 E 06 10 EN

Operator's manual

Engine-powered articulated lifts, 12 - 26 m

HA120PX - HA16X - HA16SPX

(HA46SJRT) - HA16PX (HA46JRT) -

HA18SPX (HA51SJRT) - HA18PX

(HA51JRT) - HA20PX (HA61JRT) -

HA260PX (HA80JRT)

Main Page

Other manuals for Haulotte Group HA18PX

Maintenance Book196 pages

Questions and Answers

O
Olivia HopkinsAug 7, 2025
What to do if the buzzer is constantly on in my Haulotte Group HA18PX Lifting Systems?
- M
  Mary HoffmanAug 7, 2025
  The buzzer in your Haulotte Group Lifting Systems could be activated for several reasons: * The tilt or slope may be exceeding the authorized limit; lower the arm and boom. * The platform overload indicator may be triggered; remove some weight. * The hydraulic oil temperature may be too high; allow it to cool down. * The pump might not be working because the E-stop buttons are pulled out. * Faulty fuses could be the cause; replace them. * The batteries might be discharged or faulty; recharge or replace them. * There could be poor contact on the battery cables; clean and tighten the terminals.
A
Amanda JohnstonNov 21, 2025
Why are the platform controls not responding on my Haulotte Group Lifting Systems?
- A
  andrewperkinsNov 21, 2025
  The platform controls on your Haulotte Group Lifting Systems may not be responding due to several reasons: * The ground control box selector key might be set to the ground control box position; turn it to the platform control box position. * The platform overload indicator might be active; remove some weight. * The 'Enable Switch' pedal may not be activated; keep pressure on the pedal during movement. * The button or joystick corresponding to the faulty movement might be defective; replace the knob or joystick. * The tilt or slope may be exceeding the authorized limit; lower the arm and boom. * If there's no high speed, the platform might be extended. * If there's no steering, there might not be enough hydraulic oil. * If the platform and turntable controls do not work, th...

Summary

A - Safety Precautions

2 - Pre-operation instructions

3 - Operation instructions

Prohibitions and potential risks during machine operation.

B - Intervenors Responsibility

4 - Operators responsibility

Operator's duties regarding manual, safety, and reporting issues.

5 - Inspection and maintenance

C - Machine Layout

2 - Main components

3 - Safety devices

Details on safety features like turntable rotation pin and guardrails.

4 - Labels

D - Operating Principle

2.4 - Length and Angle Sensors

2.6 - Detection of Internal Fault

2.7 - Automatic Engine Cut-out

2.8 - Load Limiting in the Platform

System to prevent operation when maximum load is exceeded.

2.9 - Chassis Tilt

Warning and restrictions when the machine is on a slope exceeding limits.

2.1 - Activation of Controls

2.2 - Drive Speed

2.3 - Movement Speed

2.10 - Radius Limitation

Function of the radius limit indicator and operational restrictions.

E - Driving

2 - Checks before use

Daily and pre-work visual inspection and functional testing.

2.3 - Periodical Checks

2.4 - Repairs and Adjustments

2.5 - Inspection; Testing Requirements

F - Special Procedure

1 - Emergency lowering

Principle and procedure for emergency platform lowering.

2 - Lowering for repairs

Principle and procedure for lowering the platform in case of power failure.

3 - Towing

4 - Loading and unloading

Principles and procedures for loading, unloading, and transport positioning.

5 - Detection of internal fault

G - Technical Characteristics

3 - Working area

4 - AS - CE standard specificities

Details on overload, functional, and stability tests as per standards.

Haulotte Group HA18PX Specifications

General

Platform Capacity	230 kg
Platform Size	1.8 m x 0.8 m
Drive Type	4WD
Maximum Slope	40%
Horizontal Outreach	10.6 m
Overall Width	2.3 m
Overall Height	2.3 m
Power Source	Diesel
Ground Clearance	0.33 m
