36 4001022490 E 02.19 USA / GB
HA18PX
C
-Familiarization
6 - Machine specifications
6.1 - MOVEMENT SPEED
To allow checking operation, refer to the following table about originally time per movement. If the
values measured by test are not equal to the following :
• Do not use the machine.
• Setting updating is needed.
Always check speed movement from the ground control box.
HA18PX - HA51JRT
Time for arm lifting 35s ± 3s
Time for descent arm 23s ± 3s
Time for raising boom 30s ± 3s
Time for descent boom 33s ± 3s
Time for continue turntable rotation 75s ± 1.5s (per 1/2 rotation)
Time for telescopic boom extension 20s ± 3s
Time for telescopic boom retraction 16s ± 3s
Time for jib lifting 34s ± 2s
Time for jib descent 35s ± 2s
Time for raising compensation 27s ± 5s
Time for lowering compensation 35s ± 5s
