HAUSSLER ALPHA - Technical Documentation; ALPHA 1-Speed Circuit Diagram

24
ALPHA circuit diagram (1-speed model)
⚠ WARNING
Danger to life from mains voltage 230 V / 50 Hz
Electric shock
 Always disconnect the device from the power supply before commencing
repair work.
 Never carry out work on the equipment electronics.
 If you have problems with the electronics, consult a trained electrician.
Posion monitoring
Operang capacitor
Lead
blue red yellow black black
Operang display
10-pin ribbon
For specialist personnel: Circuit diagrams and parts lists
