FRONT VIEW
FUNCTIONAL
DISPLAY INDICATOR PANEL
PRODUCT OVERVIEW -
Front Cover
Front Deco
Tank Lid
Spout
Jog Dial
43
REAR VIEW
.
Rear Cover
Rear Cover Bottom
Feed Water Inlet
Power Input
Flushed Water Outlet
TECHNICAL SPECIFICATIONS
NOTE:
*Flow Rate may vary depending upon feed water quality, input water pressure, condition of membrane & cartridges.
**Recovery / TDS percentage reduction may vary depending upon type of feed water, feed water pressure &
cartridges life.
***In case, input turbidity is more than 5 NTU, you need to install pre filter at an additional cost.
****In case, input water pressure goes below 0.041 MPa (6 psi), you need to install external booster pump and if
pressure is above 0.21 MPa (30 psi), you need to install pressure reducing valve at an additional cost.
*****In case, the Iron content in input water is more than 0.3 mg/L (ppm), you need to install IRON REMOVER
PLUS at an additional cost.
#The chemical preservative used in the RO membrane is of food grade quality.
PARAMETERS VALUES
Product dimensions (H x D x W) in cm (48.4 x 24.1 × 36.1) cm
Net weight ≈ 9 kg
Flow rate* Up to 25 L/h
Storage tank capacity ≈ 6 L
Purification technology Absolute safety through 100% RO
& UV technology
Purification stages 10 stages
Membrane type Thin film composite RO
membrane
Material of construction Food grade
for plastic components
Power rating (maximum) 45 W
Working voltage 1 Phase, 150 V - 250 V AC, 50 Hz
TDS reduction** ≥90%
% Recovery** ≥ 40%
System disinfection efficacy
6, 4, 3 Log reduction of bacteria, viruses & cysts
Installation type Wall mount & Counter top
Water dispensing Manual with jog dial
RECOMMENDED FEED WATER QUALITY
PARAMETERS LIMITS
Total dissolved solids Up to 2000 mg/L (ppm)
Total hardness Up to 600 mg/L (ppm)
Turbidity*** Up to 5 NTU
Feed water pressure**** 0.04 MPa (6 psi) - 0.207 MPa (30 psi)
Feed water temperature 5
0
C-45
0
C
Iron ***** Less than 0.3 mg/L
Free chlorine Less than 0.2 mg/L
